Specification

Details

Model

Confluence GRX 600 2x

Vehicle Category

EBike

Application

Gravel adventures, bikepacking

Starting Price (2025)

$3,699.00 USD

Color Options

Yellow

Sizes

49cm, 51cm, 53cm, 55cm, 57cm, 60cm

Specification

Details

Frame

Confluence, 6061-T6 aluminum, internal cable routing, 136mm spacing, 10x1mm threaded proprietary derailleur hanger

Fork

Confluence Carbon Deluxe, 402mm axle-to-crown, 50mm offset, 12x100mm thru-axle

Drivetrain Compatibility

Shimano GRX RX600, 2x11-speed

Dropouts

12x100mm (F, M12xTP1.5x120mm, thru-axle), 136mm (R, 10x1mm threaded)

Crank

Shimano GRX RX600

Chain

Shimano HG601-11

Rear Derailleur

Shimano GRX RX810

Front Derailleur

Shimano GRX RX810

Shifters

Shimano GRX RX600

Cassette

Shimano HG700-11, 11–34t, 11-speed

Specification

Details

Seating

WTB Volt (~143–155mm)

Fuel Type

Electric

Cargo Capacity

Frame bottle mounts (2), fork bottle mounts (two sets of Three-Pack mounts), rack mounts (frame and fork), fender mounts (frame and fork)

Wheels/Tyres

WTB ST i23, 32h, WTB Serra (F), MAHLE X35+ (R), straight gauge black spokes, Teravail Washburn 700c x 42mm, Durable casing, wire bead (F and R)

Brakes

Shimano GRX RX400, flat-mount, Shimano RT26 160mm rotors

Brake Levers

Shimano GRX RX600

Handlebar

Salsa Cowbell

Stem

Salsa Guide

Headset

FSA, IS41 (upper), IS52 (lower)

Saddle

WTB Volt (~143–155mm)

Seatpost

Promax SP-2016, 27.2mm

Seatpost Clamp

32.0mm

Grips

Black cork

Front Hub

WTB Serra

Rear Hub

MAHLE X35+

Rims

WTB ST i23, 32h

Spokes

Straight gauge, black

Exterior Features

Rack mounts (frame and fork), fender mounts (frame and fork), frame bottle mounts (2), fork Three-Pack mounts (two sets)

Weight

32 lb 2 oz (~14.6 kg) for 55cm

Motor

MAHLE X35+ hub-drive, 40Nm torque, Class 1, max assist speed 20 mph (32 kph)

Battery

Li-ion, 250Wh, removable for service, up to 458Wh with optional MAHLE Range Extender

Controller

MAHLE iWOC One, top-tube mounted, 3 assist levels

Charger

Included, 3 hours estimated charge time
