Specification

Details

Model

Confluence Apex 1

Vehicle Category

EBike

Application

Gravel riding with electric assist

Starting Price (2025)

$3,199.00 USD

Color Options

Avocado Green

Sizes

49cm, 51cm, 53cm, 55cm, 57cm, 60cm

Specification

Details

Frame

Confluence, 6061-T6 aluminum, internal cable routing, 136mm spacing, 10x1mm threaded proprietary derailleur hanger

Fork

Confluence Carbon, 12x100mm spacing, 50mm offset, 402mm axle-to-crown

Drivetrain Compatibility

SRAM Apex 1, 11-speed

Dropouts

12x100mm (F, M12xTP1.5x120mm), 136mm (R, 10x1mm threaded, proprietary derailleur hanger)

Crank

FSA Omega Megaexo, 40t

Chain

SRAM PC-1110

Rear Derailleur

SRAM Apex 1

Shifters

SRAM Apex 1 x 11

Cassette

SRAM PG-1130, 11-speed, 11–42t

Specification

Details

Seating

WTB Volt

Fuel Type

Electric (MAHLE 250Wh)

Cargo Capacity

Two bottle mounts, front and rear rack mounts, two sets of three-pack mounts on fork

Wheels/Tyres

WTB ST i23, 32h, WTB Serra 12x100mm hub (F), MAHLE X35+ hub (R), straight gauge black spokes, Teravail Washburn 700c x 42mm, Durable casing, wire bead

Wheel Size

700c front, 700c rear

Brakes

Tektro MD-C550, flat-mount, 160mm rotors (F, R)

Brake Levers

SRAM Apex

Handlebar

Salsa Cowbell

Stem

Salsa Guide

Headset

FSA, IS41 upper, IS52 lower

Saddle

WTB Volt

Seatpost

Promax SP-2016, 27.2mm

Seatpost Clamp

32.0mm

Grips

Black cork

Front Hub

WTB Serra, 12x100mm, 32h

Rear Hub

MAHLE X35+, 136mm

Rims

WTB ST i23, 32h

Spokes

Straight gauge, black

Exterior Features

Front and rear fender mounts, front and rear rack mounts, two bottle mounts, two sets of three-pack mounts on fork

Weight

33 lb (14.97 kg) for 57cm

Motor

MAHLE X35+ hub-drive, 40Nm torque, Class 1, 20 mph (32 kph) max assist speed, 3 assist levels

Battery

MAHLE 250Wh, Li-ion, removable for service, up to 458Wh with MAHLE Range Extender (sold separately)

Controller

MAHLE iWoc One, top-tube mounted, 3 assist levels

Charger

Included, 3 hours estimated charge time
