2025 Ram ProMaster 3500 Tradesman Cutaway 159" WB / 104" CA – Commercial Chassis
Specifications
|
Specification |
Details |
|
Model |
Tradesman Cutaway 159" WB / 104" CA |
|
Vehicle Category |
Commercial Cutaway Chassis |
|
Application |
Commercial, upfitting (e.g., box trucks, service vehicles) |
|
Starting Price (2025) |
$47,120 (MSRP, excludes $2,095 destination) |
|
Color Options |
Bright White, Black, Flame Red, Bright Silver, Sandstone, Paprika Red Pearl, Ceramic Gray, Deep Cherry Red Crystal, Granite Crystal Metallic, Patriot Blue, Spitfire Orange |
Frame & Drivetrain
|
Specification |
Details |
|
Powertrain |
3.6L Pentastar V6 |
|
Gross Horsepower |
276 hp @ 6,400 RPM |
|
Torque |
250 lb-ft @ 4,400 RPM |
|
Transmission Type |
9-speed 948TE automatic |
|
Drivetrain |
Front-wheel drive |
|
Max Towing Capacity |
6,910 lbs |
Suspension & Brakes
|
Specification |
Details |
|
Suspension |
Front: MacPherson struts with coil springs and stabilizer bar; Rear: Leaf springs with gas-pressurized shock absorbers |
|
Brakes |
4-wheel disc with ABS; Front: 11.8 in vented discs; Rear: 11.0 in solid discs |
Components & Features
|
Specification |
Details |
|
Seating |
1–3 (front, optional passenger seat or double seat) |
|
Fuel Type |
Regular unleaded gasoline |
|
Fuel Tank Capacity |
24 gal |
|
Fuel Economy |
13–17 mpg combined (est., not EPA-rated) |
|
Ground Clearance |
6.9 in |
|
Max Payload |
5,150 lbs |
|
Cargo Volume |
N/A (dependent on upfit) |
|
Wheels/Tyres |
16 in steel wheels, LT225/75R16E BSW All-Season tyres |
|
Wheel Size |
16 in x 6 in Steel |
|
Audio/Entertainment |
Uconnect 5 with 7 in touchscreen, Apple CarPlay, Android Auto, SiriusXM, 4 speakers |
|
Safety |
Driver front-impact airbag, side-mounted airbag, curtain airbags, forward-collision warning, pedestrian/cyclist emergency braking, crosswind assist, ParkView rear backup camera, tire pressure monitoring |
|
Interior Features |
Cloth or vinyl bucket seats, 4-way manual driver seat, telescoping steering wheel, push-button start, manual air conditioning, power windows, 4G LTE Wi-Fi hotspot, 1 12V DC power outlet |
|
Exterior Features |
Halogen headlights, black front/rear bumpers, black grille, manual side mirrors with turn signals |
|
Weight |
4,303 lbs (curb weight) |
|
Width |
80.3 in (without mirrors) |
|
Length |
250.6 in |
|
Max Height |
87.3 in |
