Eicher Pro 6055XP Diesel Heavy-Duty Tractor
Specifications
|
Specification |
Details |
|
Model |
Pro 6055XP |
|
GCW |
55000 kg |
|
Engine Type |
VEDX8 7.7L 6 Cylinder |
|
Max Power |
221 kW @ 2200 rpm |
|
Max Torque |
1200 Nm @ 1200-1600 rpm |
|
Emission |
BSVI |
|
Fuel Type |
Diesel |
|
Fuel Tank Capacity |
350 litre / 350 + 220 litre TFT |
|
Battery |
24V |
|
Max Speed |
80 kmph |
|
Gradeability |
28% (Crawler) |
|
Application |
heavy-duty |
Frame & Drivetrain
|
Specification |
Details |
|
Wheelbase |
4050 mm (BCS) / 4085 mm (BGS) |
|
Front Overhang |
1420 mm |
|
Turning Circle Diameter |
16 m |
|
Gearbox |
ET140 S9 |
|
Clutch |
430 mm, single plate dry |
|
Rear Axle |
Heavy Duty Fully Floating Single Reduction |
|
Chassis Type |
300x76x7 mm (BCS) / 300x90x8 mm (BGS) |
Suspension & Brakes
|
Specification |
Details |
|
Front Suspension |
Parabolic Leaf Spring with Shock Absorber |
|
Rear Suspension |
Bell Crank / Bogie |
|
Steering |
Tilt and telescopic Hydraulic power steering |
Wheels & Tyres
|
Specification |
Details |
|
Tyre Size |
295/90R20 / 11R20 (optional) |
Components & Features
|
Feature |
Details |
|
Feature: Fuel Efficiency |
Fuel Coaching |
|
Feature: Engine Performance |
MBooster+ |
|
Feature: Engine Management |
EMS |
|
Feature: Driving Control |
Cruise Control |
|
Feature: Telematics |
Eicher Live Telematics System |
