Pasquali Helios K90 RS – 4WD Tractor with Kubota Engine
Specifications
|
Specification |
Details |
|
Tractor Model |
Pasquali Helios K90 RS (4WD) |
|
Vehicle Category |
Tractor |
|
Fuel Type |
Diesel |
|
Application |
Orchards, Vineyards, Olive Groves, Greenhouses, Canopy Plantations |
Frame & Drivetrain
|
Specification |
Details |
|
Engine |
Kubota V3800-CR-T-EW03, 4 cylinders, 3769 cc, Turbo, Stage V, Diesel common rail direct injection, Liquid cooling, Electronically regulated engine speed via hand lever and button with memorize and recall function |
|
Gross Horsepower |
75 HP (54.6 kW) at 2400 rpm |
|
Max Torque |
305.4 Nm at 1500 rpm |
|
Transmission Type |
32-speed synchronised, 16 FWD + 16 REV with synchronised reverser, Min speed: 0.7 km/h, Max speed: 40 km/h, Multidisc in oil bath clutch with hydraulic control |
Suspension & Brakes
|
Specification |
Details |
|
Suspension |
Comfort seat with adjustable spring tension, safety belt, and man-on-board sensor; Optional ultra-low profile cab (170 cm height) with platform suspended on silent-block, available in Compact Clima (air conditioning, heating) or Compact Pro (pressurized, Category 4 approved) |
|
Braking System |
Multidisc in oil bath with mechanical control, acting on rear wheels with automatic 4WD engagement, Independent maneuvering brakes on rear wheels, Parking brake acting on service brakes with lever control |
Wheels & Tyres
|
Specification |
Details |
|
Tyre Size |
Front: 260/70R16, 250/80-16, 280/70R18, 250/80R18, 320/65R18; Rear: 300/70R20, 340/65R20, 320/85R20, 360/70R20, 420/65R20, 280/85R24 (11.2R24), 320/70R24, 380/70R20 |
Components & Features
|
Specification |
Details |
|
PTO Type |
Rear: 540/540E (standard), 540/1000 (optional), Independent, Multidisc in oil bath with electro-hydraulic control, Negative safety hydraulic brake, Synchronised with forwarding speed |
|
Hydraulic System |
Dual circuit with independent pumps and heat exchanger, Power steering pump: 33.1 L/min, Lift and control valves: 27.7 L/min (optional 49 L/min), Max pressure: 180 bar, 1 double-acting with float and free flow oil return (3 outlets), Optional: 2 double-acting or 1 double-acting with lockable position (7 outlets total) |
|
Hitch |
Category 1 and 2, Up/down lift with two external cylinders (standard), Optional position and draft-controlled, Ball joint lifting capacity: 2700 kg, Standard: manual third point tie rod, Optional: hydraulically controlled upper link and tie rod link arm |
|
Weight |
2400 kg (with roll-bar), 2520 kg (with cabin) |
|
Width |
1338-1908 mm |
|
Wheelbase |
1348 mm |
|
Track Width |
Front: 1098-1538 mm; Rear: 1030-1518 mm |
|
Max Length |
3918 mm |
|
Max Height |
2195-2320 mm (with roll-bar), 1700 mm (with cabin) |
|
Features |
Swinging integral OS-Frame chassis (±15°), Front-wheel drive disengagement with electro-hydraulic control, Front and rear differential lock with electro-hydraulic control, Instrument panel with analogue gauges and TFT digital colour display, Vehicle Control Unit, Street light and indicator system, Front LED working lights, Single-pole dashboard socket, Rear 7-pin and 3-pin sockets, Optional front bumper, Optional rear adjustable working light, Optional front weights (150 kg total), Optional cast iron flange weights for wheels |
