Specification

Details

Tractor Model

Pasquali Ermes 70 Dualsteer®

Vehicle Category

Orchard/Vineyard Tractor

Fuel Type

Diesel

Application

Orchards, Vineyards, Greenhouses, Municipalities

Specification

Details

Engine

Kohler KDI 2504 TCR, 4-Cylinder, 2,482 cc, Common Rail Direct Injection, Turbo Intercooler, Liquid-Cooled, Stage V

Maximum Power

63 HP (46 kW) @ 2,600 RPM

Maximum Torque

205 Nm @ 1,500 RPM

Transmission Type

24-Speed Synchronized Gearbox, 12 FWD + 12 REV with Synchronized Reverser, Min Speed: 0.7 km/h, Max Speed: 35 km/h, Multidisc in Oil Bath with Electronically-Managed Hydraulic Control, Power Clutch System, PRO-ACT System with Easy Plus™ Engagement, Smart Brake & Go Function

Steering

Dualsteer® 4-Cylinder Steering System, Hydrostatic Steering Acting on Front Wheels and Central Joint, Flow Deviator for Steering Unit

Specification

Details

Braking System

Oil Bath Discs with Hydrostatic Control, Acting on Rear Wheels, Independent Manoeuvring Brakes Acting on Rear Wheels, Parking Brake with Handle Acting on Service Brakes

Specification

Details

Tyres

Options: 7.00-18*250/80-18, 280/70R18*280/70R18 Garden, 280/70R18*320/65R18, 280/70R18*340/65R18, 260/70R20*300/70R20, 260/70R20*300/70R20 Garden, 260/70R20*250/85R20, 260/70R20*280/70R20, 260/70R20*280/70R20 PneuTrac, 31x15.50-15 XTC/STG, 33x15.50-15 XTC

Specification

Details

Chassis

Swinging Integral Chassis (±15°), OS-FRAME with Central Articulation and Steering Wheels

Drive

Permanent Four-Wheel Drive

Differential

Front and Rear with Simultaneous Locking and Electro-Hydraulic Control

Axles

Front and Rear with Planetary Reduction Units, Optional Oversized Planetary Reduction Units

PTO Type

Rear: Independent, 540/540E RPM, Synchronized with Forwarding Speed, Multidisc in Oil Bath with Electro-Hydraulic Control, Negative Safety Hydraulic Brake

Hydraulic System

Dual Circuit with Independent Pumps and Heat Exchanger, Power Steering Pump: 13 l/min, Lift/Valves Pump: 37 l/min (Optional 48 l/min), 180 bar, Standard: 1 Double-Acting with Float and Free Flow Return (3 Outlets), Optional: Up to 11 Outlets (Up/Down Lift) or 7 Outlets (Draft-Controlled Lift), Optional Joystick with Proportional Electronic Control, 48 l/min Pump, 10 Outlets

Rear Lift

1,900 kg, Category 1, Standard: Up/Down with Two External Cylinders, Optional: Position and Draft-Controlled, Normal or Quick-Couplings Cat. 1 or Cat. 1 and 2 (L-Shaped, Adjustable in Length/Width), Manual or Hydraulic Third Point Tie Rod

Driving Position

Reversible with Rotating Platform Suspended on Silent Blocks, Suspended Pedals on Rotating Control Tower, Comfort Seat with Gas Spring, Safety Belt, Man-on-Board Sensor (Standard), Optional: ‘Grammer’ or ‘Cobo’ Pneumatic Seat, Optional Cabin (VISTA or VISTA PRO, Soundproofed, ROPS/FOPS, Monocoque, Silent Blocks, LED Beacon, USB Radio, 2 USB Outlets, Ventilation/Heating or Air-Conditioning, Pressurized Cat. 4, Optional Active Carbon Filters, FULL LED Work Lights)

Dashboard

Instrument Panel with Analogue Gauges, TFT Digital Colour Display, Warning Lights, Horn

Electric System

Battery 80 Ah / 12 V, Alternator 95 A, Vehicle Control Unit, FULL LED Street Light and Indicator System, Front LED Working Lights, Rear 7-Pin and 3-Pin Sockets

Tow Hooks

Standard: Front and Rear CUNA Cat. C Adjustable in Height, Optional: Rear EC Approved, EC with Slider Frame, CUNA with Slider Frame, EC Tow Bar with Slider Frame

Safety

Front Homologated Roll-Bar with Gas Spring for Easy Lowering and Lifting

Additional Options

Front Bumper, Beacon Lamp, Rear Adjustable Working Light, Self Cleaning System™, Front Weights: 110 kg, Wheel Weights: 45 kg Each (18" Wheels), 50 kg Each (20" Wheels), Dual Floating System™ Hydraulic Suspension, Silver and Bordeaux ‘Special Edition’ Livery

Weight

With Roll-Bar: 1,830 kg, With Cabin: 1,960 kg

Wheelbase

1,480 mm

Ground Clearance

214–299 mm

Dimensions

Length: 3,529 mm, Width: 1,150–1,764 mm, Height (Roll-Bar): 2,215–2,300 mm, Height (Cabin): 2,145–2,230 mm
