Pasquali Dionis 85 RS – 4WD Tractor with Kohler Engine
Specifications
|
Specification |
Details |
|
Tractor Model |
Pasquali Dionis 85 RS (4WD) |
|
Vehicle Category |
Tractor |
|
Fuel Type |
Diesel |
|
Application |
Orchards, Vineyards, Olive Groves, Greenhouses, Canopy Plantations |
Frame & Drivetrain
|
Specification |
Details |
|
Engine |
Kohler KDI 2504 TCR, 4 cylinders, 2482 cc, Turbo/Intercooler, Stage V, Common rail direct injection (2000 bar), Liquid cooling, Electronically regulated engine speed via console with increase/decrease, memorize/recall, switch off, and minimum speed functions, Counter-balance shafts |
|
Gross Horsepower |
75.3 HP (55.4 kW) at 2300 rpm |
|
Max Torque |
300 Nm at 1500 rpm |
|
Transmission Type |
32-speed synchronised, 16 FWD + 16 REV with synchronised reverser, Min speed: 0.7 km/h, Max speed: 40 km/h, Multidisc in oil bath clutch with electronically-managed proportional hydraulic control, Optional EASYDRIVE® electro-hydraulic power shuttle with 5 reactivity levels, Power Clutch System, PRO-ACT System, Smart Brake & Go function |
Suspension & Brakes
|
Specification |
Details |
|
Suspension |
Platform suspended on silent-blocks, Comfort seat with safety belt and man-on-board sensor, Optional lowered 'Kab' or 'Grammer' pneumatic seat, Optional COMPACT PRO low-profile pressurized cab (Category 4) with monocoque body on silent-blocks |
|
Braking System |
Oil bath discs with hydrostatic control, acting on four wheels with automatic 4WD engagement, Independent maneuvering brakes on rear wheels, Parking brake acting on rear transmission with lever control, Optional automatic Brake-Off with proportional action (standard with cab) |
Wheels & Tyres
|
Specification |
Details |
|
Tyre Size |
Front: 260/70R16, 280/70-18, 320/65R18, 340/65R18; Rear: 300/70R20, 340/65R20, 360/70R20, 320/70R24, 380/70R20, 420/65R24, 280/85R24 (11.2R24) |
Components & Features
|
Specification |
Details |
|
PTO Type |
Rear: 540/540E (standard), 540/1000 (optional), Independent, Multidisc in oil bath with electro-hydraulic control, Negative safety hydraulic brake, Synchronised with forwarding speed |
|
Hydraulic System |
Dual circuit with independent pumps and heat exchanger, Power steering pump: 33.5 L/min, Lift and control valves: 29.5 L/min (optional 51 L/min), Max pressure: 180 bar, Standard: 2 double-acting + free flow oil return (5 outlets), Optional: 1 single-acting and 1 double-acting (8 outlets) or 1 double-acting and 1 double-acting with float (9 outlets), Optional joystick with proportional electronic control |
|
Hitch |
Category 1 and 2, Raising/lowering with two external rams (standard), Optional position and draft control, Ball joint lifting capacity: 2700 kg, Standard: manual third point tie rod, Optional: hydraulically controlled upper link and tie rod link arm, Optional front lift with 800 kg capacity and 2 double-acting valves (4 outlets) |
|
Fuel Tank Capacity |
78 L (with roll-bar), 58 L (with cabin) |
|
Weight |
2460 kg (with roll-bar), 2640 kg (with cabin) |
|
Width |
1350-1878 mm |
|
Wheelbase |
1365 mm |
|
Track Width |
Front: 1098-1538 mm; Rear: 1034-1518 mm |
|
Max Length |
3935 mm |
|
Max Height |
2216-2316 mm (with roll-bar), 1765-1865 mm (with cabin) |
|
Features |
Swinging integral OS-Frame chassis (±15°), Front-wheel drive disengagement with electro-hydraulic control, Front and rear differential lock with electro-hydraulic control, TFT color display (hours, engine rpm, speed, PTO rpm, fuel consumption, battery voltage, time, particulate filter status), Analogue instrumentation (engine rpm, coolant temperature, fuel level), Vehicle Control Unit, Street light and indicator system, Front LED working lights, Single-pole dashboard socket, Rear 7-pin and 3-pin sockets, Optional front bumper, Optional rear adjustable working light, Optional Self Cleaning System™, Optional front weights (150 kg), Optional wheel weights (50 kg each), Optional cast iron flange weights (70 kg each for 24” rear wheels), Optional black and white ‘Special Edition’ livery |
