Nissan Patrol Y61 – Off-Road SUV
Specifications
|
Specification |
Details |
|
Powertrain |
3.0L inline-4 turbo-diesel (ZD30DDTi); Optional: 4.8L inline-6 petrol (TB48DE) |
|
Power |
Diesel: 158-170 hp @ 3600 rpm; Petrol: 245-280 hp @ 4800 rpm |
|
Torque |
Diesel: 354-371 Nm @ 2000 rpm; Petrol: 400-420 Nm @ 3600 rpm |
|
Transmission |
5-speed manual or 4-speed automatic (diesel); 5-speed automatic (petrol) |
|
Brakes |
Front: Ventilated Disc; Rear: Ventilated Disc |
|
Suspension |
Front/Rear: Coil spring, live axle with 3-link (optional rear sway bar disconnect) |
|
Wheel Size |
16-inch to 17-inch alloy or steel |
|
Tyres |
265/70 R16 to 275/65 R17 |
|
Weight |
~2300-2800 kg (kerb, depending on configuration) |
|
Dimensions (LxWxH) |
SWB: 4395 x 1840 x 1855 mm; LWB: 5050 x 1940 x 1855 mm |
|
Seat Height |
~750 mm (approximate) |
|
Fuel Tank Capacity |
95-135 litres (dual tanks in some markets) |
|
Mileage |
Diesel: ~7-9 kmpl; Petrol: ~5-7 kmpl |
|
Ground Clearance |
235-240 mm |
|
Price (Middle East, Ex-2015) |
~$30,000-50,000 (~₹25-42 lakh, India estimated) (Year-2025) |
Frame & Drivetrain
|
Specification |
Details |
|
Chassis |
Body-on-frame (ladder chassis) |
|
Powertrain Type |
Diesel or Petrol |
|
Gearbox |
5-speed manual or 4/5-speed automatic |
|
Drivetrain |
Part-time 4WD with low-range, locking rear differential |
Suspension & Brakes
|
Specification |
Details |
|
Front Suspension |
Coil spring, live axle with 3-link |
|
Rear Suspension |
Coil spring, live axle with 5-link, optional sway bar disconnect |
|
Front Brake |
Ventilated Disc |
|
Rear Brake |
Ventilated Disc |
Wheels & Tyres
|
Specification |
Details |
|
Wheels |
16-inch to 17-inch alloy or steel |
|
Tyres |
265/70 R16 to 275/65 R17 |
|
Wheel Size |
16-inch to 17-inch |
Components & Features
|
Specification |
Details |
|
Seat |
PVC, fabric, or leather (higher trims), 5/7-seater |
|
Steering |
Hydraulic power-assisted, manual tilt |
|
Instrument Cluster |
Analog gauges with 4x4 indicators |
|
Features |
AM/FM radio with CD player, manual AC, power windows/locks (higher trims), optional rear cooler |
|
Safety Features |
Dual front airbags, ABS with EBD, fuel cutoff system, optional side airbags |
Available Colors
|
Specification |
Details |
|
Colors |
White, Black, Silver, Desert Gold, Green (market-dependent) |
