New Holland WORKMASTER™ 25 – Compact Tractor for Landscaping
Specifications
|
Specification |
Details |
|
Tractor Model |
WORKMASTER™ 25 |
|
Vehicle Category |
Compact Tractor |
|
Fuel Type |
Diesel |
|
Application |
Food Plot, Livestock, Landscaping |
Frame & Drivetrain
|
Specification |
Details |
|
Engine |
3 cylinders, Naturally Aspirated, 1.3 L (80.4 cu.in.) |
|
Gross Horsepower |
24.4 HP (18.2 kW) @ 2500 RPM |
|
PTO Power |
Gear: 19.2 HP (14.3 kW); Hydrostatic: 17.1 HP (12.8 kW) @ 540 RPM |
|
Transmission Type |
12x12 Gear or 3-Range Hydrostatic |
|
Maximum Forward Speed |
Gear: 13.8 mi/h (22.2 km/h); Hydrostatic: 15.3 mi/h (24.7 km/h) |
Suspension & Brakes
|
Specification |
Details |
|
Front Axle |
Four-Wheel Drive (Standard) |
|
Rear Differential Lock |
Mechanical |
|
Brake Type |
Wet, Multi-Disc |
Components & Features
|
Specification |
Details |
|
Emissions Level |
Tier 4B Final |
|
Alternator |
50 A |
|
Fuel Tank Capacity |
28 L (7.4 gal) |
|
PTO Type |
Independent Electro-Hydraulic Engagement |
|
Rear PTO Speed |
540 RPM |
|
Mid PTO Speed |
2000 RPM (Standard on Hydrostatic; Optional on Gear) |
|
Cruise Control |
Standard on Hydrostatic Models |
|
Hydraulic Flow (Implement) |
7.9 gal/min (30 L/min) |
|
Hydraulic Flow (Steering) |
Gear: 4.6 gal/min (17.5 L/min); Hydrostatic: 4.6 gal/min (17.5 L/min) |
|
Total Hydraulic Flow |
Gear: 12.5 gal/min (47.5 L/min); Hydrostatic: 12.5 gal/min (47.5 L/min) |
|
Remote Control Valves |
1 or 2 (Optional) |
|
3-Point Hitch |
Category I, Telescopic Stabilizers, Fixed Link Ends |
|
3-Point Hitch Lift Capacity (Ball Ends) |
820 kg (1808 lb) |
|
3-Point Hitch Lift Capacity (24 in Behind Ball Ends) |
650 kg (1433 lb) |
|
Compatible Front Loaders |
200LC |
|
200LC Loader: Lift Capacity (500 mm Forward, Max Height) |
551 kg (1214 lb) |
|
200LC Loader: Lift Capacity (Bucket Pivot, Max Height) |
726 kg (1600 lb) |
|
200LC Loader: Breakout Force (500 mm Forward) |
874 kg (1926 lb) |
|
200LC Loader: Breakout Force (Bucket Pivot) |
1196 kg (2637 lb) |
|
200LC Loader: Max Lift Height (Bucket Pivot) |
2395 mm (94.3 in) |
|
200LC Loader: Max Dump Angle |
51 degrees |
|
200LC Loader: Max Rollback Angle |
41 degrees |
|
200LC Loader: Lift Time |
3.1 seconds |
|
200LC Loader: Lowering Time |
2.0 seconds |
|
200LC Loader: Bucket Dump Time |
1.7 seconds |
|
200LC Loader: Bucket Retract Time |
2.7 seconds |
|
Wheelbase |
1674 mm (65.9 in) |
|
Length |
2976 mm (117.2 in) |
|
Width |
1374 mm (54.1 in) |
|
Height (Top of ROPS) |
2241 mm (88.2 in) |
|
Weight |
1120 kg (2469 lb) |
|
Operator Platform |
Foldable ROPS |
