New Holland WORKMASTER™ 105 – Agricultural Tractor by New Holland
Specifications
|
Specification |
Details |
|
Tractor Model |
WORKMASTER™ 105 |
|
Vehicle Category |
Tractor |
|
Fuel Type |
Diesel |
|
Application |
Agricultural Tractor |
Frame & Drivetrain
|
Specification |
Details |
|
Engine Model |
F5C Bharat TREM Stage-IV |
|
Engine Type |
4 Cylinder, 16 valve HPCR |
|
Engine CC/Bore-Stroke |
3387 CC / 99 mm x 110 mm |
|
Engine Power |
79 kW (106 HP) @ 2300 ERPM |
|
Air Cleaner |
Dry Type with Auto Cleaning |
|
Clutch |
Multi disk wet type with Power Shuttle |
|
Transmission Type |
Fully Synchromesh with Creeper Gear |
|
Number of Gears |
20 Forward + 20 Reverse |
|
Rear Axle Type |
Heavy-Duty Planetary Reduction |
Suspension & Brakes
|
Specification |
Details |
|
Brake Type |
Hydraulically actuated Rear Oil Immersed Multi Disk Brake |
|
Steering Type |
Power Steering |
Wheels & Tyres
|
Specification |
Details |
|
Front Tyres |
12.4 in x 24 in (315 mm x 607 mm) |
|
Rear Tyres |
18.4 in x 30 in (467 mm x 762 mm) |
Components & Features
|
Specification |
Details |
|
Lift Capacity |
3500 kg with Dual Assist Ram |
|
Lift-O-Matic |
Yes |
|
PTO Clutch |
Electro Hydraulic Multi Disk Wet Type |
|
PTO Standard |
540 @ 1876 ERPM |
|
1000 PTO |
1000 @ 2125 ERPM |
|
Fuel Tank Capacity |
90 L |
|
Battery & Alternator |
110 Ah Battery & 120 Amp Alternator |
|
Overall Length |
4125 mm |
|
Width |
2180 mm |
|
Height |
2625 mm |
|
Wheelbase |
2130 mm |
|
Ground Clearance |
410 mm |
|
Weight |
3215 kg |
|
Safety & Comfort |
ROPS, FOPS & Canopy, Air Suspended adjustable seat with seat belt |
|
Optional Features |
19.5L24 R4 Rear Tyres, 70 kg FWC, 8x40 kg FW, 2x50 kg RW, Swinging Drawbar |
