New Holland T7.190 – Row Crop Tractor by New Holland
Specifications
|
Specification |
Details |
|
Tractor Model |
T7.190 |
|
Vehicle Category |
Row Crop Tractor |
|
Fuel Type |
Diesel |
|
Application |
Medium-Scale Agriculture, Haymaking, Loading, Manure Spreading |
Frame & Drivetrain
|
Specification |
Details |
|
Engine Power |
150 HP (110 kW) Rated; 190 HP (140 kW) Max with EPM |
|
Engine Type |
FPT NEF (6-cylinder, Turbocharged, Air-to-Air Intercooled) |
|
Engine Capacity |
6.7 Litres (411 cu in) |
|
Engine Speed at Rated Power |
2000 RPM |
|
Transmission Type |
Range Command (40 km/h, 18x6, 19x6); Power Command (40 km/h, 18x6, 19x6; 50 km/h, 19x6); Auto Command CVT (40 km/h, 50 km/h) |
Suspension & Brakes
|
Specification |
Details |
|
Front Suspension |
Terraglide™ (Optional) |
|
Cab Suspension |
Comfort Ride (Optional for Classic, Standard for SideWinder) |
Components & Features
|
Specification |
Details |
|
Drive |
4WD |
|
Rear PTO |
125 HP (93 kW) |
|
Hydraulics Type |
Closed Centre Load Sensing (CCLS) |
|
Hydraulic Pump |
113 l/min (29.8 gal/min) Range/Power Command; 140 l/min (37 gal/min) Auto Command |
|
Max Valves (Rear) |
Mechanical or Electrohydraulic |
|
Max Lift Capacity (Rear) |
5362 kg (11821 lb) / 6616 kg (14586 lb) with 90 mm/100 mm opt. |
|
Max Lift Capacity (Front) |
3571 kg (7873 lb) |
|
Wheelbase |
2710 mm (107.6 in) |
|
Total Weight |
6810 kg (15013 lb) |
|
Fuel Tank Capacity |
330 L (87 gal) |
|
DEF Capacity |
48 L (13 gal) |
|
Emissions Compliance |
Tier 4B/Final – Stage V |
