New Holland Excel 4710 4WD – Agricultural Tractor by New Holland
Specifications
|
Specification |
Details |
|
Tractor Model |
Excel 4710 4WD |
|
Vehicle Category |
Tractor |
|
Fuel Type |
Diesel |
|
Application |
Agricultural Tractor |
Frame & Drivetrain
|
Specification |
Details |
|
Engine Model |
FPT 8035.05D.943 |
|
Engine Type |
Naturally Aspirated |
|
Engine Power |
35.1 kW (47 HP) |
|
Rated RPM |
2100 |
|
Air Cleaner Type |
Dry Air Cleaner with Clogging Sensor |
|
Clutch |
Double Clutch with IPTO Lever |
|
Transmission Type |
Constant Mesh AFD Side Shift |
|
Number of Gears |
8 Forward + 8 Reverse |
|
Rear Axle Type |
Straight Axle Planetary Drive |
Suspension & Brakes
|
Specification |
Details |
|
Brake Type |
Oil Immersed Multi Disc Brake |
|
Steering Type |
Power Steering |
Wheels & Tyres
|
Specification |
Details |
|
Front Tyres |
9.5 in x 24 in (241.3 mm x 609.6 mm) - MHD Axle, 9.5 in x 20 in (241.3 mm x 508 mm) - STS Axle |
|
Rear Tyres |
14.9 in x 28 in (378.46 mm x 711.2 mm), 13.6 in x 28 in (345.44 mm x 711.2 mm) |
Components & Features
|
Specification |
Details |
|
Lift Capacity |
1800 kg High Precision Hydraulic |
|
Lift-O-Matic |
Yes |
|
PTO Type |
Eptraa PTO - 540S |
|
PTO HP |
43 HP (32.06 kW) |
|
Fuel Tank Capacity |
60 L |
|
Battery & Alternator |
88 Ah & 35 Amp |
|
Overall Length |
3540 mm |
|
Width |
2070 mm |
|
Height |
2415 mm |
|
Wheelbase |
2005 mm |
|
Ground Clearance |
393 mm |
|
Weight |
2255 kg |
|
Additional Features |
International EXCEL Style, CAT EYE Headlamps, LED Fender Lamps, Synchro Shuttle, Heavy Duty Front Axle Support, Multisensing with DRC Valve, Tipping Trailer Pipe, 55kg FWC, Hot Air Deflector, Exhaust Muffler, Neutral Safety Switch, Clutch Safety Lock, Antiglare Rear View Mirror, Semi Flat Platform, Polymer Fuel Tank |
|
Optional Features |
Remote Valve, Economy PTO, ROPS with Canopy, Deluxe Seat with Belt, HI-Lug Tyre, 8 Forward + 2 Reverse Gears, 16 Forward + 4 Reverse Gears, 16 Forward + 16 Reverse Gears, 540E PTO, Reverse PTO, GSPTO |
