Specification

Details

Model

New Holland Braud 8.50L

Vehicle Category

Grape Harvester

Fuel Type

Diesel

Application

Grapes

Specification

Details

Engine

FPT NEF, 4 cylinders, Common Rail injection, Stage V ECOBlue™ Compact HI-eSCR

Gross Horsepower

144 HP (106 kW)

Transmission Type

Hydrostatic with anti-skid braking

Specification

Details

Suspension

Optional front axle suspension

Specification

Details

Front Tyres

340/85R24, 400/80R24, or 420/70R24

Rear Tyres

440/80R28, 480/70R28, or 540/65R28

Specification

Details

Harvesting Head

Vineyard row spacing: Large (>1.6 m), 10 SDC shakers (max 16), Sealing length: 2.1 m, Compatible implements: Berthoud sprayers, Provitis leaf remover, trimmer, pre-pruner

Shaking System

SDC (Shaking Dynamic Control), 10 shakers (max 16), Electric shaker rod aperture adjustment, Jackless shaking system, Fixed or optimized shaking plate, Three silent blocks for vibration isolation

Collection System

Noria basket conveyor system, Flexible polyurethane baskets

Cleaning System

High capacity cleaning conveyors (600 mm)

Destemmer

Standard destemmer, Optional Opti-Grape™ II (finger rotor with mesh, turbine air cushion), MOG transfer auger

Hopper

Stainless steel hoppers, 3600 L

Fuel Tank Capacity

240 L (diesel), 41 L (AdBlue)

Width

2990 mm (base unit), 2550 mm (with harvesting head at rear wheels)

Wheelbase

2820 mm

Height

3690 mm (max with cab, harvesting head on ground), Hopper tipping: 2700-3050 mm (under hopper), 2950-3300 mm (tipping axis)

Ground Clearance

2000-2600 mm

Features

IntelliView IV Plus touchscreen monitor (12”), IMS 2.0, Auto Comfort seat (heated/ventilated), Blue Cab 4, 12 LED headlights, Bluetooth radio, 2 cameras (optional +2), Electric ladder platform, Safety belt, Emergency hammer, Operator presence sensor, Optional Row Tracking System (RTS), Optional FieldOps telematics, Reversible cooling fan, CDHA auto height/tilt correction (600 mm lift), CustomSteer
