New Holland Braud 10.90X Olive 2 Hoppers – 182 HP Olive Harvester for Super High Density Orchards
Specifications
|
Specification |
Details |
|
Model |
New Holland Braud 10.90X Olive 2 Hoppers |
|
Vehicle Category |
Olive Harvester |
|
Fuel Type |
Diesel |
|
Application |
Super High Density olive orchards |
Frame & Drivetrain
|
Specification |
Details |
|
Engine |
FPT NEF, 6 cylinders, Turbo with Intercooler, Stage V ECOBlue™ HI-eSCR 2 |
|
Gross Horsepower |
182 HP (134 kW) |
|
Transmission Type |
Heavy duty high-efficiency hydrostatic with Poclain Twin Lock, 30 kph road speed (market dependent), Cruise control with radar |
Suspension & Brakes
|
Specification |
Details |
|
Suspension |
Front axle hydraulic suspension |
|
Brakes |
Electric park brake with brake pedal and seat button |
Wheels & Tyres
|
Specification |
Details |
|
Front Tyres |
400 mm |
|
Rear Tyres |
600 mm |
Components & Features
|
Specification |
Details |
|
Harvesting Head |
Super High Density olive orchard (1-1.35 m row spacing, 3.5-4 m height), 42 SDC shakers, Quick coupling, Hydraulic horizontal shaking rod spacing, Ground sensor for autolevelling, Automatic swing lock system, Front tunnel for tree entry |
|
Shaking System |
SDC (Shaking Dynamic Control), 42 shakers, Flexible rear rod fixation, 2000 mm shaker height, 99.9% olive detachment |
|
Collection System |
Noria basket system, 2x71 XXL baskets, 2500 mm sealed length, Tool-free tensioning system, Noria pressure sensor |
|
Cleaning System |
High capacity central cleaning conveyors (460 mm), Secondary lateral dispatching conveyors (230 mm), Upper cleaning fan with rear exhaust |
|
Hopper |
2 stainless steel hoppers, 4000 L, Hydraulic heavy duty auger, Simultaneous unloading |
|
Fuel Tank Capacity |
270 L (diesel), 41 L (AdBlue) |
|
Width |
3000 mm (base unit), 3240 mm (min at rear wheels with 600 mm tyres) |
|
Wheelbase |
3300 mm |
|
Height |
4040 mm (max with cab, harvesting head on ground), Hopper tipping: 3100 mm (under hopper), 3330 mm (tipping axis) |
|
Ground Clearance |
2310-3060 mm (under tractor frame) |
|
Features |
IntelliView IV touchscreen monitor (26.4 cm), IMS 2.0, Automated Crop Setup (ACS), Blue Cab 4 (optional, Cat 2/4 filtration, auto air-con, heated/ventilated seat, LED lights, cool box), 2 cameras (optional +2), 12 LED lights with Light Control Panel, Bluetooth radio, 2 USB plugs, Fold-down laptop table, Coat hook, Elastic stowage net, Front/rear sunshades, Electrically actuated ladder with LED light, Retractable right mirrors, Optional Row Tracking System (RTS), Optional olive weighing system with printer, Optional MyPLM Connect Telematics, Centralized greasing, 600h service intervals |
