New Holland 3600 TX Super Heritage Edition 4WD – Agricultural Tractor by New Holland
Specifications
|
Specification |
Details |
|
Tractor Model |
3600 TX Super Heritage Edition 4WD |
|
Vehicle Category |
Tractor |
|
Fuel Type |
Diesel |
|
Application |
Agricultural Tractor |
Frame & Drivetrain
|
Specification |
Details |
|
Engine Model |
FPT 8035.05D.943 |
|
Engine Type |
Naturally Aspirated |
|
Engine Power |
35.1 kW (47 HP) |
|
Rated RPM |
2100 |
|
Air Cleaner Type |
Oil Bath Type with Pre-cleaner |
|
Clutch |
Double Clutch |
|
Transmission Type |
Constant Mesh AFD Side Shift |
|
Number of Gears |
8 Forward + 8 Reverse Synchro Shuttle |
|
Rear Axle Type |
Straight Axle Planetary Drive |
Suspension & Brakes
|
Specification |
Details |
|
Brake Type |
Oil Immersed Multi Disc Brake |
|
Steering Type |
Power Steering |
Wheels & Tyres
|
Specification |
Details |
|
Front Tyres |
9.5 in x 24 in (241.3 mm x 609.6 mm) - MHD Axle |
|
Rear Tyres |
14.9 in x 28 in (378.46 mm x 711.2 mm) |
Components & Features
|
Specification |
Details |
|
Lift Capacity |
1800 kg High Precision Hydraulic |
|
Lift-O-Matic |
Yes |
|
PTO Type |
Eptraa PTO - 540S, Reverse PTO |
|
PTO HP |
43 HP (32.06 kW) |
|
Fuel Tank Capacity |
55 L |
|
Battery & Alternator |
88 Ah & 35 Amp |
|
Overall Length |
3470 mm |
|
Width |
1810 mm |
|
Height |
2430 mm (2510 mm with ROPS + Canopy) |
|
Wheelbase |
2005 mm |
|
Ground Clearance |
370 mm |
|
Weight |
2210 kg |
|
Additional Features |
Heavy Duty Front Axle Support, Deluxe Driver Seat, Multisensing with DRC Valve, Tipping Trailer Pipe, Neutral Safety Switch, Clutch Safety Lock, Antiglare Rear View Mirror, Semi Flat Platform, Polymer Fuel Tank, Paddy Special - Double Metal Face Sealing |
|
Optional Features |
IPTO Lever, Speedtech 16 Forward + 4 Reverse Gears, Economy PTO, 540E PTO, GSPTO, ROPS with Canopy, Stabilizer Bar, 55kg FWC, Remote Valve, 8.3 in x 20 in (210.82 mm x 508 mm) Front Tyres - STS Axle |
