New Holland 3032 NX – Agricultural Tractor by New Holland
Specifications
|
Specification |
Details |
|
Tractor Model |
3032 NX |
|
Vehicle Category |
Tractor |
|
Fuel Type |
Diesel |
|
Application |
Agricultural Tractor |
Frame & Drivetrain
|
Specification |
Details |
|
Engine Model |
T-IIIA, Simpson 324 |
|
Engine Type |
Naturally Aspirated |
|
Engine Power |
26.1 kW (35 HP) |
|
Rated RPM |
2000 |
|
Air Cleaner Type |
Oil bath type with Pre-cleaner |
|
Clutch |
Single Clutch |
|
Transmission Type |
Constant Mesh AFD Side Shift |
|
Number of Gears |
8 Forward + 2 Reverse |
|
Rear Axle Type |
Outboard Reduction |
Suspension & Brakes
|
Specification |
Details |
|
Brake Type |
Oil Immersed Multi Disc Brake |
|
Steering Type |
Mechanical/Power Steering |
Wheels & Tyres
|
Specification |
Details |
|
Front Tyres |
6 in x 16 in (152.4 mm x 406.4 mm) |
|
Rear Tyres |
13.6 in x 28 in (345.44 mm x 711.2 mm) |
Components & Features
|
Specification |
Details |
|
Lift Capacity |
1500 kg High Precision Hydraulic |
|
Lift-O-Matic |
Yes |
|
PTO Type |
540S |
|
PTO HP |
34 HP (25.35 kW) |
|
Fuel Tank Capacity |
42 L |
|
Battery & Alternator |
75 Ah & 35 Amp |
|
Overall Length |
3290 mm |
|
Width |
1660 mm |
|
Height |
2280 mm |
|
Wheelbase |
1930 mm |
|
Ground Clearance |
385 mm |
|
Weight |
1750 kg |
|
Max Road Speed |
33.06 KMPH @ Rated RPM |
|
Additional Features |
Heavy Duty Front Axle Support, Std. Driver Seat, Softek Clutch, Multisensing with DRC Valve, Tipping Trailer Pipe, 90 kg HD Front Bumper, Neutral Safety Switch, Antiglare Rear View Mirror, Semi Flat Platform |
|
Optional Features |
None |
