TVS Radeon 2025 – Commuter Motorcycle
Specifications
|
Specification |
Details |
|
Engine |
109.7cc, 4-stroke, single-cylinder, air-cooled, SOHC, BS6 Phase 2 |
|
Power |
8.08 PS @ 7350 rpm |
|
Torque |
8.7 Nm @ 4500 rpm |
|
Transmission |
4-speed manual |
|
Mileage |
70 kmpl (user-reported, mixed) |
|
Fuel Tank Capacity |
10L |
|
Kerb Weight |
116 kg |
|
Dimensions (LxWxH) |
2025x705x1080 mm |
|
Wheelbase |
1265 mm |
|
Ground Clearance |
180 mm |
|
Seat Height |
785 mm |
|
Suspension (Front/Rear) |
Telescopic fork/Swingarm with 5-step adjustable shocks |
|
Brakes (Front/Rear) |
240 mm disc or 130 mm drum/110 mm drum, SBT |
|
Tyres (Front/Rear) |
2.75 R18/3.00 R18, tubeless |
|
Variants |
Base, Digi Disc, Special Edition |
|
Price (Ex-Showroom, Delhi) |
₹75,346–₹82,346(Year - 2025) |
Engine & Transmission
|
Specification |
Details |
|
Engine Type |
Air-cooled, 4-stroke, single-cylinder, SOHC, fuel-injected |
|
Displacement |
109.7cc |
|
Bore & Stroke |
53.5 mm x 48.8 mm |
|
Compression Ratio |
10:1 |
|
Maximum Power |
8.08 PS @ 7350 rpm |
|
Maximum Torque |
8.7 Nm @ 4500 rpm |
|
Fuel System |
Bosch fuel injection, ETFi |
|
Transmission |
4-speed manual |
|
Clutch |
Wet, multi-plate |
Dimensions & Weight
|
Specification |
Details |
|
Overall Length |
2025 mm |
|
Overall Width |
705 mm |
|
Overall Height |
1080 mm |
|
Wheelbase |
1265 mm |
|
Ground Clearance |
180 mm |
|
Seat Height |
785 mm |
|
Kerb Weight |
116 kg |
|
Payload Capacity |
130 kg |
|
GVW |
246 kg |
Chassis & Suspension
|
Specification |
Details |
|
Frame Type |
Single cradle tubular |
|
Front Suspension |
Telescopic fork, oil-damped |
|
Rear Suspension |
Swingarm with 5-step adjustable hydraulic shocks |
Brakes & Tyres
|
Specification |
Details |
|
Front Brake |
240 mm disc or 130 mm drum |
|
Rear Brake |
110 mm drum |
|
Braking System |
Synchronized Braking Technology (SBT) |
|
Front Tyre |
2.75 R18, tubeless |
|
Rear Tyre |
3.00 R18, tubeless |
|
Wheels |
18-inch alloy |
Electricals & Features
|
Specification |
Details |
|
Battery |
12V, 4Ah MF |
|
Starting Method |
Electric and kick |
|
Instrumentation |
Digital cluster with econometer |
|
Lighting |
LED DRL, halogen headlamp, halogen tail lamp, halogen indicators |
|
Features |
USB charger, side-stand indicator, econometer, ETFi technology, E20 fuel compatible |
|
Safety Features |
SBT, side-stand cut-off |
Available Colors
|
Specification |
Details |
|
Colors |
Metal Black, Black, Red Black, Titanium Grey, Blue Black, Starlight Blue, Royal Purple, All Black |
