TVS XL100 Win Edition 2025 – Premium Utility Moped
Specifications
|
Specification |
Details |
|
Engine |
99.7cc, 4-stroke, single-cylinder, air-cooled, SOHC, BS6 Phase 2 |
|
Power |
4.35 PS @ 6000 rpm |
|
Torque |
6.5 Nm @ 3500 rpm |
|
Transmission |
Single-speed, centrifugal clutch |
|
Mileage |
55 kmpl (user-reported, mixed) |
|
Fuel Tank Capacity |
4L (1.25L reserve) |
|
Kerb Weight |
89 kg |
|
Dimensions (LxWxH) |
1895x670x1065 mm |
|
Wheelbase |
1228 mm |
|
Ground Clearance |
158 mm |
|
Seat Height |
780 mm |
|
Suspension (Front/Rear) |
Telescopic hydraulic/Swingarm with hydraulic shock |
|
Brakes (Front/Rear) |
110 mm drum/110 mm drum, SBT |
|
Tyres (Front/Rear) |
2.50 R16/2.50 R16, tube-type |
|
Variants |
Single |
|
Price (Ex-Showroom, Delhi) |
₹61,247(Year-2025) |
Engine & Transmission
|
Specification |
Details |
|
Engine Type |
Air-cooled, 4-stroke, single-cylinder, SOHC, fuel-injected |
|
Displacement |
99.7cc |
|
Bore & Stroke |
51 mm x 48.8 mm |
|
Compression Ratio |
10:1 |
|
Maximum Power |
4.35 PS @ 6000 rpm |
|
Maximum Torque |
6.5 Nm @ 3500 rpm |
|
Fuel System |
Bosch fuel injection, ETFi |
|
Transmission |
Single-speed |
|
Clutch |
Centrifugal wet |
Dimensions & Weight
|
Specification |
Details |
|
Overall Length |
1895 mm |
|
Overall Width |
670 mm |
|
Overall Height |
1065 mm |
|
Wheelbase |
1228 mm |
|
Ground Clearance |
158 mm |
|
Seat Height |
780 mm |
|
Kerb Weight |
89 kg |
|
Payload Capacity |
130 kg |
|
GVW |
219 kg |
Chassis & Suspension
|
Specification |
Details |
|
Frame Type |
Reinforced tubular underbone |
|
Front Suspension |
Telescopic hydraulic |
|
Rear Suspension |
Swingarm with hydraulic shock |
Brakes & Tyres
|
Specification |
Details |
|
Front Brake |
110 mm drum |
|
Rear Brake |
110 mm drum |
|
Braking System |
Synchronized Braking Technology (SBT) |
|
Front Tyre |
2.50 R16, tube-type |
|
Rear Tyre |
2.50 R16, tube-type |
|
Wheels |
16-inch spoke |
Electricals & Features
|
Specification |
Details |
|
Battery |
12V, 3Ah MF |
|
Starting Method |
i-TOUCH keyless start, electric, and kick |
|
Instrumentation |
Analogue cluster with fuel reserve indicator |
|
Lighting |
LED DRL, halogen headlamp, halogen tail lamp, halogen indicators |
|
Features |
i-TOUCH start with ISG, USB charger, detachable rear seat, large floorboard, chrome mirrors, chrome exhaust shield, beige inner panels, split seats, ETFi technology (15% better mileage), E20 fuel compatible, low fuel warning |
|
Safety Features |
SBT, side-stand cut-off, fall sensor (engine cut-off in 3 seconds) |
Available Colors
|
Specification |
Details |
|
Colors |
Delight Blue, Beaver Brown |
