Specification

Details

Tractor Model

X7.623 P6-Drive

Vehicle Category

Utility Tractor

Fuel Type

Diesel

Application

Farming, Contracting, Heavy-Duty Fieldwork

Specification

Details

Engine

6 cylinders, 6.7 L, FPT N67, 24 Valves, Turbo Intercooler, Electronically-Controlled High Pressure Common Rail, Iso-Mounted on Cast Iron Chassis

Rated Horsepower

205 HP (151 kW) @ 2200 RPM

Maximum Horsepower

215 HP (158 kW) without EPM, 225 HP (166 kW) with EPM @ 1900 RPM

Maximum Torque

904 Nm without EPM, 921 Nm with EPM @ 1400 RPM

Torque Backup

36% (41% with EPM)

Transmission Type

P6-Drive Powershift, 6 Powershift Speeds, 5 Robotized Ranges, 30 FWD + 15 REV (Standard), 54 FWD + 27 REV with Creeper (Optional)

Transmission Control

EasyPilot on RH Console (Efficient), EasyPilot with Multi-Function Armrest (Premium), Smart APS Auto Powershift, Stop & Action De-Clutch

Minimum Speed

3.2 km/h without Creeper, 0.4 km/h with Creeper

ECO Engine Speed at 40 km/h

1505 RPM

ECO Engine Speed at 50 km/h

1880 RPM (Optional)

Specification

Details

Front Axle

Rigid (Standard), IFS Independent Front Wheel Suspension (Optional), Electrohydraulic 4WD Engagement

Front Differential Lock

Fully Electrohydraulic

Rear Axle

Flanged (Standard), Bar Axle (Optional), Fully Electrohydraulic Differential Lock

Braking System

5 Oil-Cooled Discs (Rear), Automatic 4WD Engagement While Braking (Front), Engine Brake, Pneumatic Brake System with 2 or 2+1 Lines per MR or 2-Line Hydraulic Brake System per MR (Optional, 40 km/h only)

Cab Suspension

4-Post Mounted on Silent Blocks (Standard), Mechanical or Electrohydraulic Semi-Active Suspension (Optional)

Specification

Details

Front Tyre Size

600/60R30 (IR 700 mm)

Rear Tyre Size

710/60R42 (IR 925 mm)

Max Track Width

2550 mm

Specification

Details

Emissions System

Tier 3

Maintenance Interval

1000 hours

Fuel Tank Capacity

320 L

AdBlue/DEF Tank Capacity

52 L

Cooling System Capacity

29 L

PTO Type

Rear: Electrohydraulic Multidisc Clutch with Modulated Engagement, 540/540E/1000/1000E, Front: Electrohydraulic Multidisc Clutch with Modulated Engagement, 1000 RPM (Optional)

PTO Speeds

Rear: 540/540E/1000/1000E (2000/1588/2002/1590 RPM), Front: 1000 RPM (1920 RPM)

Hydraulic System

Closed-Centre Load Sensing (CCLS), 123 L/min (Standard), 160 L/min (Optional, Premium), 52 L/min Steering Pump, 3 Mechanical (80 L/min) or 3-5 Electrohydraulic Remote Valves (100 L/min, Efficient), 3-6 Electrohydraulic (100 L/min, Premium), 3-Section Flow Divider with 60 L/min per Section (Optional, Premium), Free Flow Return, Power Beyond Ready (Optional), 2 Electrohydraulic Mid-Mounted Remote Valves with Multi-Function Joystick (100 L/min, Optional)

Rear 3-Point Hitch

Electronically-Controlled, Category III, Ball Ends with Quick-Hitch Hooks, Lower Link Draft/Position/Mixed/Float Control, 6400 kg Lift Capacity (80 mm Ram, Efficient), 9300 kg Lift Capacity (100 mm Ram, Premium)

Front 3-Point Hitch

Electronically-Controlled, Category III N, Ball Ends with Quick-Hitch Hooks, Position Control, 3500 kg Lift Capacity (Optional)

Front Loader

McCormick Front Loader, Controlled by Joystick (Optional)

Wheelbase

2820 mm

Height from Top of Cab to Rear Axle Centre

2180 mm (2295 mm with PSM)

Max Height over Cab

3044 mm (3159 mm with PSM)

Overall Length with Front Weights

5360 mm

Shipping Weight

8000 kg

Gross Vehicle Weight

13000 kg

Operator Platform

Première 4-Post Cab, In-Cab Noise Level 70 dB(A), Manual Climate Control (Efficient) or Automatic Climate Control (Premium), Deluxe Air Suspension Seat (Standard), Super Deluxe with Dynamic Damping, Alcantara, Ventilation (Optional, Premium), Hide-Away Buddy Seat, Radio Ready (Efficient) or Radio DAB MP3 with Bluetooth (Premium), 12 Halogen (Efficient) or 18 Halogen/20 LED Work Lights (Premium), Beacon Lights

Onboard Technology

DSM 12" Touch Screen Monitor (Premium), MyFunctions, MyLights, MyHMF (Premium), Front/Rear ISObus (Optional), PSM Precision Steering Management (EGNOS or RTK NTRIP, Optional), Fleet & Remote Diagnostics Management (1-Year Standard, 3/5-Year Optional)
