Specification

Details

Tractor Model

X6.125 XtraShift

Vehicle Category

Compact Utility Tractor

Fuel Type

Diesel

Application

Soil Preparation, Sowing, Haymaking, Barn Management, High-Speed Transport

Specification

Details

Engine

4 cylinders, 3.6 L, FPT F36, Turbo Aftercooled, Electronically-Controlled High Pressure Common Rail System

Rated Horsepower

119 HP (88 kW) @ 2200 RPM

Maximum Horsepower

119 HP (88 kW) @ 1900 RPM

Maximum Torque

518 Nm @ 1300 RPM

Torque Backup

36%

Transmission Type

XtraShift Electrohydraulic, 3-Stage HML Powershift, 36 FWD + 12 REV, 48 FWD + 16 REV with Creeper

Transmission Control

Hand Lever, Reverse Power Shuttle (RPS) with Modulation Control

Minimum Speed

1.5 km/h without Creeper, 0.3 km/h with Creeper (IR 750 mm)

Engine Speed at 40 km/h

1893 RPM

Engine Speed at 50 km/h

2200 RPM

Specification

Details

Front Axle

Rigid Wide with Brakes (Standard), Rigid Narrow with Brakes (Optional), Suspended with Integrated Brakes (Optional), 4WD, Hydralock Full Locking Differential

Rear Axle

Flanged Type, Electrohydraulic Differential Lock

Braking System

Automatic 4WD Engagement When Braking (Standard), Front Brakes (Optional), Ring Piston Hydraulic Brake (Rear), Dual-Line Hydraulic Brake as per MR (Standard), Single-Line Hydraulic Brake or CUNA (Optional), Dual-Line Pneumatic Brake (Optional, Aftermarket), Park Lock (Optional)

Cab Suspension

Total View Slim Mounted on Silent Blocks (Standard), Mechanical Cab Suspension (Optional)

Specification

Details

Maximum Tyres Front

480/65R24 (IR 800 mm)

Maximum Tyres Rear

540/65R38 (IR 800 mm)

Specification

Details

Emissions System

Stage V - Tier 4 Final, DOC + DPF + SCR

Maintenance Interval

500 hours

Fuel Tank Capacity

170 L (44.9 gal)

AdBlue/DEF Tank Capacity

23 L (6.1 gal)

Cooling System Capacity

10 L (2.6 gal)

PTO Type

Rear: Electrohydraulic, 540/540E/1000/1000E with HML, 1-3/8” Shaft with 6 Splines (Standard) or 21 Splines (Optional), Ground Speed PTO (Optional), Front: Electrohydraulic Multidisc Clutch with Modulated Engagement, 1000 RPM, 1-3/8” Shaft with 6 Splines (Optional)

PTO Speeds

Rear: 1944 RPM (540), 1580 RPM (540E), 1952 RPM (1000), 1586 RPM (1000E), Front: 1920 RPM (1000)

Hydraulic System

CCLS Closed Center Load Sensing, 110 L/min for Hitch and Remotes + 38 L/min for Steering, Up to 3 Mechanical Rear Remote Valves (Standard), Up to 3 Mechanical + 2 Electronic Rear Remote Valves (Optional), 2 Mechanical Mid-Mounted Remote Valves with Multifunction Joystick, 80 L/min, Flow Divider/Flow Selector (Optional), Free-Flow Return (Standard), Hydraulic Oil Take-Out 34 L (Standard), 44 L Max with Additional Tank (Optional)

Rear 3-Point Hitch

Category II, Fixed Ball Ends (Standard), Quick-Hitch Hooks or Telescopic Lower Links (Optional), Electronic Control, 6000 kg with 2 Assistor Rams

Front 3-Point Hitch

Category II, Quick-Hitch Hooks, Electronically-Controlled, 2250 kg (Optional)

Front Loader

McCormick M30 Front Loader, 1880 kg Lift Capacity, Controlled by Multifunction Joystick (Optional)

Wheelbase

2420 mm

Max Height

2623 mm without Beacon Lights, Measured with Tyres 380/70R24 - 480/70R34

Max Height from Top of Cab to Rear Axle Centre

1935 mm

Max Length

4256-4552 mm with Front Weights, Measured with Tyres 380/70R24 - 480/70R34

Steering Radius

4400 mm, Measured with Tyres 480/65R24 - 540/65R38

Shipping Weight

4800 kg (10582 lb)

Gross Vehicle Weight

8500 kg (18739 lb) with Wide Front Axle, 8000 kg (17637 lb) with Narrow Front Axle

Operator Platform

Total View Slim Cab Mounted on Silent Blocks, In-Cab Noise Level 78 dB(A), Filtration Category CAT 2, Heat and Ventilation (Standard), Manual Climate Control (Optional), Opening Front Windscreen, Mechanical Seat (Standard), Comfort Air Suspension Seat (Optional), Hide-Away Buddy Seat (Optional), Radio Ready with 2 Speakers (Standard), Radio DAB MP3 with 2 Speakers, Bluetooth, Aux-In, Integrated Microphone (Optional), 6 Halogen Work Lights (2 Roof Front, 2 Roof Rear, 2 Bonnet, Standard), 8 Halogen Work Lights (2 Roof Front, 2 Roof Rear, 2 Bonnet, 2 Handles LED, Optional), 10 LED Work Lights (2 Roof Front, 4 Roof Rear, 2 Bonnet, 2 Handles, Optional), Beacon Lights (Left Side Standard, Left and Right Side or Without Optional)

Onboard Technology

PSM Precision Steering Management and ISOBus Ready (Optional), PSM and ISOBus with EGNOS Full Kit (Topcon AES-35 Steering Wheel, X25 8.4” Touchscreen, AGS-2 Aerial, Optional), PSM and ISOBus with RTK NTRIP Full Kit (Optional), Fleet Management Ready (Standard), Fleet & Remote Diagnostics Management and McCormick Farm Pro Pack (1 Year Standard, 3 or 5 Years Optional, Selected Markets)
