Specification

Details

Tractor Model

X5.085

Vehicle Category

Utility Tractor

Fuel Type

Diesel

Application

Ploughing, Tilling, Harrowing, Sowing, Haymaking, Livestock Farming, Transport

Specification

Details

Engine

4 cylinders, 3.4 L, FPT F34, Turbo Aftercooled, Electronically-Controlled High Pressure Common Rail System

Rated Horsepower

75 HP (56 kW) @ 2200 RPM

Maximum Horsepower

75 HP (56 kW) @ 1400-2200 RPM

Maximum Torque

375 Nm @ 1400 RPM

Torque Backup

56%

Transmission Type

Mechanical (Standard), Electrohydraulic (Optional), 12 FWD + 12 REV with Synchro Shuttle or RPS (Standard), 24 FWD + 24 REV with RPS and Hi-Lo (Optional), 36 FWD + 12 REV with RPS and HML (Optional), Creeper (Optional)

Transmission Control

Hand Lever, Synchro Shuttle (Standard), Reverse Power Shuttle (RPS) with Modulation Control (Optional)

Minimum Speed

1.61 km/h (12 FWD + 12 REV), 1.35 km/h (Hi-Lo), 1.46 km/h (HML) without Creeper, 0.36 km/h (12 FWD + 12 REV), 0.30 km/h (Hi-Lo), 0.32 km/h (HML) with Creeper (IR 700 mm)

Engine Speed at 40 km/h

1901 RPM (Hi-Lo/HML, IR 700 mm)

Specification

Details

Front Axle

Rigid, 4WD, Limited Slip Differential (Standard), Hydralock Full Locking Differential (Optional)

Rear Axle

Flanged Type, Electrohydraulic Differential Lock

Braking System

Automatic 4WD Engagement When Braking, Ramp Brakes (Rear), Two-Line Hydraulic Brake as per MR (Optional), Single-Line Hydraulic Brake or CUNA (Optional), Two-Line Pneumatic Brake (Optional, Aftermarket)

Cab Suspension

Total View Slim Cab Mounted on Silent Blocks

Specification

Details

Maximum Tyres Front

340/85R24 (IR 575 mm)

Maximum Tyres Rear

420/85R34 (IR 750 mm)

Specification

Details

Emissions System

Stage V - Tier 4 Final, DOC + DPF

Maintenance Interval

500 hours

Fuel Tank Capacity

103 L (27.2 gal)

Cooling System Capacity

10 L (2.6 gal)

PTO Type

Rear: Mechanical (Standard), Electrohydraulic (Optional), 540/540E (Standard), 540/1000 or 540/540E/1000/1000E (Optional), 1-3/8” Shaft with 6 Splines (Standard) or 21 Splines (Optional), Ground Speed PTO (Optional), Front: Electrohydraulic Multidisc Clutch with Modulated Engagement, 1000 RPM, 1-3/8” Shaft with 6 Splines (Optional)

PTO Speeds

Rear: 1944 RPM (540), 2261 RPM (540E), 1935 RPM (1000), 1621 RPM (1000E), Front: 1920 RPM (1000)

Hydraulic System

Open-Centre, 56 L/min for Hitch and Remotes + 30 L/min for Steering, 1-3 Mechanical Rear Remote Valves, 2 Mechanical Mid-Mounted Remote Valves with Multifunction Joystick, 80 L/min, Flow Selector/Flow Divider (Optional), Free-Flow Return, Hydraulic Oil Take-Out up to 35 L

Rear 3-Point Hitch

Category II, Fixed Ball Ends (Standard), Quick-Hitch Hooks or Telescopic Lower Links (Optional), Mechanical (Standard), Mechanical with ELS or Electronic (Optional), Ergonomic Lift System with Hydraulic Damping (Optional), 3900 kg

Front 3-Point Hitch

Category II, Quick-Hitch Hooks, 1600 kg (Optional)

Front Loader

McCormick M15 Front Loader, 1500 kg Lift Capacity, Controlled by Multifunction Joystick (Optional)

Wheelbase

2171 mm

Max Height

2485 mm without Beacon Lights, Measured with Tyres 280/85R24 - 420/85R30

Max Height from Top of Cab to Rear Axle Centre

1828 mm

Max Length

4297 mm with Front Weights, Track Width 1643-2402 mm, Measured with Tyres 280/85R24 - 420/85R30

Steering Radius

4700 mm, Measured with Tyres 340/85R24 - 420/85R34

Shipping Weight

3700 kg (8157 lb)

Gross Vehicle Weight

5800 kg (12787 lb)

Operator Platform

Total View Slim Cab Mounted on Silent Blocks, In-Cab Noise Level 77 dB(A), Filtration Category Cat. 2, Heating and Ventilation (Standard), Manual Climate Control (Optional), Opening Rear Windscreen, Comfort Air Suspension Seat (Optional), Trainer Seat (Optional), Radio Ready (Standard), Radio DAB MP3 with 2 Speakers, Bluetooth, Aux-In, Integrated Microphone (Optional), 4 Halogen Work Lights (2 Roof Front, 2 Roof Rear, Standard), 8 LED Work Lights (2 Roof Front, 2 Roof Rear, 2 Bonnet, 2 Door Handles, Optional), Beacon Lights (Left and Right Side Standard, Left Side Optional)

Onboard Technology

Speed Socket (ISO 11786, Optional), ADS+ Advanced Driving System, PSM Ready with EazySteer (Optional), PSM with EGNOS, X25 8.4” Touchscreen and AGS-2 Antenna (Optional), PSM with RTK NTRIP (Optional, AT Spare Parts), Fleet & Remote Diagnostics Management and McCormick Farm Pro Pack (1 Year Standard, 3 or 5 Years Optional, Selected Markets)
