McCormick B95 MAX – Utility Tractor for Field and Farm Tasks
Specifications
|
Specification |
Details |
|
Tractor Model |
B95 MAX |
|
Vehicle Category |
Utility Tractor |
|
Fuel Type |
Diesel |
|
Application |
Field and Farm Tasks |
Frame & Drivetrain
|
Specification |
Details |
|
Engine |
4 cylinders, 4.4 L, Perkins, Aspirated, Direct Injection, Dry Element Full View Air Filter |
|
Maximum Horsepower |
88 HP (64.5 kW) @ 1400 RPM |
|
Maximum Torque |
305 Nm @ 1400 RPM |
|
Transmission Type |
Mechanical, 12 FWD + 12 REV with Synchro Shuttle |
Suspension & Brakes
|
Specification |
Details |
|
Front Axle |
4WD without Hydralock, without Brakes |
|
Differential Locks |
Mechanical Rear Differential Lock |
|
Braking System |
Ramp Brakes, without Front Brakes |
|
Trailer Braking System |
EEC Export Version |
Wheels & Tyres
|
Specification |
Details |
|
Max Rear Tyre Size |
480/70 R34 (2WD, IR 750), 13.6 R38 (4WD, IR 750) |
Components & Features
|
Specification |
Details |
|
Fuel Tank Capacity |
95 L |
|
Emissions System |
Tier 0, without After-Treatment System |
|
PTO Type |
Mechanical, Ground Speed PTO |
|
PTO Speeds |
540/1000 RPM |
|
Hydraulic System |
54 L/min (Hitch) + 24 L/min (Steering), 1 to 2 Mechanical Remote Valves, Free Flow Return |
|
Rear Hydraulic Hitch |
Mechanical, Category II, Lifting Capacity 3100 kg |
|
Operator Platform |
ROPS Platform, Mechanical Seat |
|
Shipping Weight |
3500 kg |
|
Gross Vehicle Weight |
5350 kg |
|
Wheelbase |
2224 mm (2WD), 2316 mm (4WD) |
|
Max Height |
2580 mm (measured with tyres IR 725) |
