Massey Ferguson 9563 SMART 4WD (12+4) - IPTO – 4WD Agricultural Tractor by Massey Ferguson

Images:

1

2

Specifications

Specification	Details
Model	Massey Ferguson 9563 SMART 4WD (12+4) - IPTO
Overall Length	3,890 mm
Overall Width	1,830 mm
Wheelbase	1,972 mm
Total Weight	2,810 kg
Fuel Type	Diesel
Application	4WD Agricultural Tractor
Fuel Tank Capacity	65 L
Max Speed	31.3 km/h @ 2200 RPM

Frame & Drivetrain

Specification	Details
Cylinders	3
Cubic Capacity	2,590 cc
Fuel Injection Pump	Common Rail Injection System
Power Range	44.1 kW (63 hp)
Clutch Type	Split Torque Clutch
Transmission Type	Partial Synchro Mesh
Number of Speeds	12 Forward + 4 Reverse
Forward Speed	31.3 km/h @ 2200 RPM

Suspension & Brakes

Specification	Details
Brake Type	Oil Immersed Brake
Steering Type	Power Steering

Wheels & Tyres

Specification	Details
Tyre Dimensions	24.13 cm x 60.96 cm (9.5 x 24) front, 42.93 cm x 71.12 cm (16.9 x 28) rear

Components & Features

Feature	Details
PTO Type	IPTO PTO, six-splined shaft
PTO Speed	540 RPM @ 1789 ERPM
Hydraulics Lifting Capacity	2,500 kgf
Additional Features	SMART key, SMART cluster, mat foot step, glass heat deflectors, auxiliary pump, front weights (4 nos), spool valve, hitch rail, rear wheel weight - 35 kg (each side)
