Massey Ferguson 9563 Smart 4WD (8+8) - IPTO – 4WD Agricultural Tractor by Massey Ferguson

Images:

1

2

Specifications

Specification	Details
Tractor Model	Massey Ferguson 9563 Smart 4WD (8+8) - IPTO
Vehicle Category	4WD Tractor
Overall Length	3890 mm
Overall Width	1830 mm
Wheelbase	1972 mm
Total Weight	2810 kg
Fuel Type	Diesel
Application	4WD Agricultural Tractor
Fuel Tank Capacity	65 L
Max Speed	31.3 km/h

Frame & Drivetrain

Specification	Details
Engine Make / Type	SIMPSONS / Water cooled
Cylinders	3
Cubic Capacity	2590 cc
Fuel Injection Pump	Common Rail Injection System
Clutch Type	Split Torque Clutch
Transmission Type	Comfimesh
Number of Speeds	8 Forward + 8 Reverse
Power Range	44.1 kW (63 hp)

Suspension & Brakes

Specification	Details
Brake Type	Oil Immersed Brake
Steering Type	Power Steering

Wheels & Tyres

Specification	Details
Tyre Dimensions	9.5 x 24 (24.13 cm x 60.96 cm) Front, 16.9 x 28 (42.93 cm x 71.12 cm) Rear

Components & Features

Specification	Details
PTO Type	IPTO PTO, Six-splined shaft
PTO Speed (Standard)	540 RPM @ 1789 ERPM
Hydraulics Lifting Capacity	2500 kgf
Accessories	SMART key, SMART cluster, Mat foot step, Glass heat deflectors, Auxiliary pump, Front weights (4 nos), Spool valve, Hitch rail, Rear wheel weight - 35 kgs (each side)

* All the images are screenshots!
* Data has been taken from official website (Publicly Available)!
