Massey Ferguson 241 DI DynaTrack – 2WD Agricultural Tractor by Massey Ferguson
Specifications
|
Specification |
Details |
|
Model |
Massey Ferguson 241 DI DynaTrack |
|
Overall Length |
3,560 mm |
|
Overall Width |
1,650 mm |
|
Overall Height |
2,400 mm |
|
Wheelbase |
1,935 mm for field applications; 2,035 mm for haulage |
|
Total Weight |
1,880 kg |
|
Fuel Type |
Diesel |
|
Application |
2WD Agricultural Tractor |
|
Fuel Tank Capacity |
55 L |
|
Max Speed |
31.8 kmph |
Frame & Drivetrain
|
Specification |
Details |
|
Engine |
SIMPSONS S325.1 TIII A |
|
Cylinders |
3 |
|
Cubic Capacity |
2,500 cc (2.50L) |
|
Fuel Injection Pump |
Inline |
|
Power Range |
31.33 kW (42 hp) |
|
Clutch Type |
Dual diaphragm |
|
Transmission Type |
Fully constant mesh |
|
Number of Speeds |
12 Forward + 12 Reverse |
|
Forward Speed |
31.8 kmph |
Suspension & Brakes
|
Specification |
Details |
|
Brake Type |
Multi disc oil immersed brakes |
|
Steering Type |
Manual steering / Power steering |
Wheels & Tyres
|
Specification |
Details |
|
Tyre Dimensions |
15.24 cm x 40.64 cm (6.00 x 16) front, 34.54 cm x 71.12 cm (13.6 x 28) rear |
Components & Features
|
Feature |
Details |
|
PTO Type |
Quadra PTO, six-splined shaft |
|
PTO Speed |
540 RPM @ 1789 ERPM |
|
Hydraulics Lifting Capacity |
2,050 kgf |
|
Three-point Linkage and Controls |
Draft, position and response control, links fitted with CAT-1 (Combi Ball) |
|
Electricals |
12 V 80 Ah Battery, 12 V 36 A Alternator |
|
Features |
2-in-1 VersaTech front axle for adjustable wheelbase, Super Shuttle, adjustable hitch, stylish bumper, push type pedals, adjustable seat, oil pipe kit, telescopic stabilizer |
