Mahindra 305 Orchard – 2WD Agricultural Tractor by Mahindra
Specifications
|
Specification |
Details |
|
Model |
Mahindra 305 Orchard |
|
Fuel Type |
Diesel |
|
Application |
2WD Agricultural Tractor |
Frame & Drivetrain
|
Specification |
Details |
|
Engine Type |
High-Powered |
|
Cylinders |
3 |
|
Power Range |
15.7 to 25.7 kW (21 to 35 hp) |
|
Maximum Torque |
115 Nm |
|
Rated RPM |
2000 r/min |
|
Drive |
2WD |
|
Clutch Type |
Single |
|
Transmission Type |
Partial Constant Mesh |
|
Number of Gears |
6 Forward + 2 Reverse |
Suspension & Brakes
|
Specification |
Details |
|
Brake Type |
Oil Immersed Brakes (OIB) |
|
Steering Type |
Power |
Wheels & Tyres
|
Specification |
Details |
|
Rear Tyres |
284.48 mm x 609.6 mm (11.2 in x 24 in) |
Components & Features
|
Feature |
Details |
|
PTO Type |
Single Speed |
|
PTO RPM |
540 |
|
Hydraulics Lifting Capacity |
1200 kg |
|
Three-point Linkage and Controls |
Powerful Hydraulics |
|
Design Feature |
Narrow Width |
|
PTO Feature |
Best-in-class PTO Power |
|
Service Interval |
250 hours |
