2023 Liv Intrigue X Advanced E+ EL 1 20MPH – Women's Electric Mountain Bike
Specifications
|
Specification |
Details |
|
Model |
Intrigue X Advanced E+ EL 1 20MPH |
|
Vehicle Category |
Women's Electric Mountain Bike |
|
Application |
Trail riding and singletrack for women |
|
Starting Price (2025) |
$9,500 USD |
|
Color Options |
Airglow/Black |
|
Sizes |
XS (5'0" - 5'4"), S (5'2" - 5'7"), M (5'5" - 5'9"), L (5'7" - 5'11") |
Frame & Drivetrain
|
Specification |
Details |
|
Frame |
Advanced-grade composite frame, Advanced-grade rear triangle, Advanced forged composite upper rocker, 140mm Maestro suspension system, MX (front 29", rear 27.5") |
|
Fork |
Fox 36 Performance Elite Live Valve E-Tuned 29er, 150mm travel, 44mm offset, Fit4 damper, Kabolt-X 110, electronic adaptive suspension, e-bike integrated |
|
Rear Shock |
Fox Float X Live Valve, 185x52.5mm Trunnion mount, electronic suspension, e-bike integrated |
|
Crank |
Praxis Performance Carbon e-crank arms, XS:160mm, S/M:165mm, L:170mm, SRAM X-SYNC Eagle 36T chain ring |
|
Chain |
SRAM GX Eagle PowerLock |
|
Shifters |
SRAM AXS Rocker Paddle, wireless electronic shifting |
|
Front Derailleur |
MRP 1X HD2 custom co-molded chain guide |
|
Rear Derailleur |
SRAM GX Eagle AXS |
Components & Features
|
Specification |
Details |
|
Motor |
SyncDrive Pro2 85Nm, powered by Yamaha, Class 1, Max Assist Speed: 20MPH |
|
Battery |
EnergyPak Smart Compact 400, EnergyPak Plus range extender compatible |
|
Range |
21-80 miles (400Wh), range extender compatible |
|
Controller |
RideControl Ergo 3, RideControl GO integrated in top tube |
|
Display |
ANT+ Wireless display compatible |
|
Seating |
Liv Sylvia E+ |
|
Fuel Type |
Electric |
|
Wheels/Tyres |
Maxxis Minion DHF 29x2.5" Foldable, TLR, EXO [F]; Maxxis Dissector 27.5x2.4" Foldable, TLR, EXO [R] |
|
Wheel Size |
29" (F), 27.5" (R) |
|
Brakes |
SRAM Code R, hydraulic disc, 220mm [F], 200mm [R] |
|
Brake Levers |
SRAM Code R |
|
Handlebar |
Giant Contact SLR Trail, carbon, 760mm (XS-S), 800mm (M-L) |
|
Stem |
Giant Contact SLR Trail, integrated, 40/45/50mm Reach, 7/9 degree Sweep Adjust System |
|
Headset |
Giant integrated |
|
Saddle |
Liv Sylvia E+ |
|
Seatpost |
Rad+ travel adjust dropper, 30.9mm, XS/S:100-140mm, M:140-170mm, L:170-200mm |
|
Grips |
Liv Tactal Pro-E Single Lock-On Grips |
|
Front Hub |
TRX 2 MTB Alloy Hub, 6 Bolt, 110x15mm |
|
Rear Hub |
TRX 2 MTB Alloy Hub, 6 Bolt, Pawl Driver (3 Pawl 30T) SRAM XD, 148x12mm |
|
Rims |
TRX 2 Hookless Clincher, 29" [F], 27.5" [R], 30mm inner width |
|
Exterior Features |
Tubeless kit (liquid, valves, levers, manual, tool) |
|
Weight |
Approximately 18.82 kg (41 lbs 8 oz) - Size Small |
