Landini Serie 7-230 Robo-Six – Heavy-Duty Utility Tractor for Field and Loader Work
Specifications
|
Specification |
Details |
|
Tractor Model |
Serie 7-230 Robo-Six |
|
Vehicle Category |
Heavy-Duty Utility Tractor |
|
Fuel Type |
Diesel |
|
Application |
Ploughing, Harrowing, Sowing, Planting, Harvesting, Loader Work |
Frame & Drivetrain
|
Specification |
Details |
|
Engine Power |
205 HP (151 kW) Rated, 215 HP (158 kW) Max, 225 HP (166 kW) Max with Dual Power at 1900 RPM |
|
Engine Type |
FPT NEF 67 (6-cylinder, Turbo Intercooled, 24 valves, Iso-mounted on Cast Iron Chassis) |
|
Engine Capacity |
6700 cm³ |
|
Engine Speed at Rated Power |
2200 RPM |
|
Transmission Type |
Robo-Six (54F/27R with Creeper, 0.4 km/h min; 30F/15R without Creeper, 3.2 km/h min) |
Suspension & Brakes
|
Specification |
Details |
|
Front Suspension |
IFS (Independent Front Wheels Suspension, Optional); Rigid (Standard) |
|
Cab Suspension |
Iso-mounted (Standard); Mechanical or Electro-Hydraulic Semi-Active (Optional) |
Wheels & Tyres
|
Specification |
Details |
|
Front Tyres (Standard) |
540/65R30 |
|
Standard Tyres Rear |
650/65R42 |
Components & Features
|
Specification |
Details |
|
Drive |
Electro-Hydraulic MFWD (Auto Engagement on Braking) |
|
Rear PTO |
540/540E/1000/1000E (2000/1588/2002/1590 RPM) |
|
Front PTO |
1000 RPM (Optional, Electro-Hydraulic Multidisc) |
|
Hydraulics Type |
Closed-Centre Load Sensing (CCLS) |
|
Hydraulic Pump |
123 l/min (Active); 160 l/min (Dynamic); 44 l/min (Steering) |
|
Max Valves (Rear) |
2-3 Mechanical + 1 Electro-Hydraulic (Active, 80 l/min); 3-6 Electro-Hydraulic (Dynamic, 100 l/min) |
|
Max Valves (Mid-Mount) |
2 (Electro-Hydraulic, 100 l/min) |
|
Max Lift Capacity (Rear) |
6400 kg (Active); 9300 kg (Dynamic) |
|
Max Lift Capacity (Front) |
3500 kg (Optional) |
|
Wheelbase |
2820 mm |
|
Steering Radius |
5400 mm |
|
Overall Width |
2550 mm |
|
Overall Height |
3044 mm (Cab without Beacon); 3159 mm (with PSM); 2180 mm (Rear Axle to Cab Roof); 2295 mm (with PSM) |
|
Overall Length |
5360 mm (with Front Weights) |
|
Total Weight |
8000 kg; 13000 kg (Gross Vehicle Weight) |
|
Fuel Tank Capacity |
320 L |
|
DEF Capacity |
52 L |
|
Emissions Compliance |
Stage V / Tier 4 Final (HI-eSCR2) |
