Landini REX4-080 – Specialized Tractor for Orchards and Vineyards
Specifications
|
Specification |
Details |
|
Tractor Model |
REX4-080 (F/GE/GB/GT) |
|
Vehicle Category |
Specialized Tractor |
|
Fuel Type |
Diesel |
|
Application |
Orchards, Vineyards |
Frame & Drivetrain
|
Specification |
Details |
|
Engine Power |
75 HP (55 kW) Rated; 75 HP (55 kW) Max at 1500 RPM |
|
Engine Type |
Deutz AG TCD 2.9 L4 HT (4-cylinder, Turbocharged, 8 valves) |
|
Engine Capacity |
2900 cm³ |
|
Engine Speed at Rated Power |
2200 RPM |
|
Transmission Type |
Speed Four (12+12); Power Four Hi-Lo (24+24, 32+32 with Creeper); T-Tronic HML (36+12, 48+16 with Creeper) |
Suspension & Brakes
|
Specification |
Details |
|
Front Suspension |
Suspended (Optional for F/GT) |
|
Cab Suspension |
Hydro Silent Blocks |
Wheels & Tyres
|
Specification |
Details |
|
Standard Tyres Rear |
380/70R24 (F); 360/70R24 (GE); 360/70R20 (GB); 420/70R24 (GT) |
Components & Features
|
Specification |
Details |
|
Drive |
4WD (Electro-Hydraulic Engagement) |
|
Rear PTO |
540/540E (Standard); 540/1000, 540/540E/1000/1000E, Ground Speed (Optional) |
|
Front PTO |
1000 RPM (Optional, F/GE/GT) |
|
Hydraulics Type |
Open-Centre, Dual Pump (Standard); Triple Pump (Optional) |
|
Hydraulic Pump |
58 l/min + 30 l/min (Standard); 30 l/min + 58 l/min + 36 l/min (88 l/min for Hitch/Remotes, Optional) |
|
Max Valves (Rear) |
2 Mechanical (Standard); 3 Mechanical or 3 Electrohydraulic (Optional) |
|
Max Valves (Mid-Mount) |
1 or 3 Electrohydraulic (Optional) |
|
Max Lift Capacity (Rear) |
2700 kg (Standard); 3400 kg (GT with Assistor Rams) |
|
Max Lift Capacity (Front) |
1700 kg (F/GE/GT, Optional) |
|
Wheelbase |
2140 mm |
|
Overall Width |
1340-1690 mm (F); 1415-1530 mm (GE); 1400-1510 mm (GB); 1510-2100 mm (GT) |
|
Overall Height |
1710 mm (ROPS to Rear Axle); 1500 mm (Cab to Rear Axle); 825-885 mm (Hood to Rear Axle) |
|
Total Weight |
2800 kg (Shipping); 5250 kg (Gross Vehicle Weight) |
|
Fuel Tank Capacity |
65 L (F/GE/GB); 70 L (GT) |
|
DEF Capacity |
7.5 L |
|
Emissions Compliance |
Stage V / Tier 4 Final (EGR + DOC + DPF) |
