Landini Discovery II 90BW – Utility Tractor for General Agricultural Tasks
Specifications
|
Specification |
Details |
|
Tractor Model |
Discovery II 90BW |
|
Vehicle Category |
Utility Tractor |
|
Fuel Type |
Diesel |
|
Application |
General Agricultural Tasks |
Frame & Drivetrain
|
Specification |
Details |
|
Engine |
4 cylinders, 4 L, SIMPSON, Turbo Aftercooled, Tier 0 |
|
Maximum Horsepower |
90 HP (66.2 kW) @ 2050 RPM |
|
Maximum Torque |
378 Nm @ 1300 RPM |
|
Transmission Type |
Mechanical, 12 FWD + 12 REV |
Suspension & Brakes
|
Specification |
Details |
|
Rear Braking System |
Ramp Brakes, Wet Disc Brakes |
Wheels & Tyres
|
Specification |
Details |
|
Front Tyres (Standard) |
18.4x30 (2WD/4WD, IR 725 mm) |
|
Standard Tyres Rear |
18.4x30 (2WD/4WD, IR 725 mm) |
Components & Features
|
Specification |
Details |
|
Emissions System |
Tier 0, No After-Treatment |
|
Fuel Tank Capacity |
65 L (17.2 gal) |
|
Clutch |
Independent Dry Dual Clutch (12+12) |
|
PTO Type |
Mechanical, 540/540E RPM |
|
Hydraulic System |
33+27 L/min |
|
Remote Valves |
2 Double-Acting |
|
Rear 3-Point Hitch |
Mechanical Control, 2300 kg |
|
Wheelbase |
2165 mm (2WD), 2230 mm (4WD) |
|
Shipping Weight |
2990 kg (6592 lb, 2WD), 3216 kg (7090 lb, 4WD) |
|
Operator Platform |
ROPS Frame (Standard), Canopy (Optional) |
|
Front Axle |
2WD (Optional), 4WD (Standard) |
|
Rear Axle |
Mechanical Differential Lock |
