Landini 7-180 Robo-Six – High-Performance Utility Tractor for Heavy-Duty Tasks
Specifications
|
Specification |
Details |
|
Tractor Model |
7-180 Robo-Six |
|
Vehicle Category |
High-Performance Utility Tractor |
|
Fuel Type |
Diesel |
|
Application |
Heavy-Duty Agricultural Tasks |
Frame & Drivetrain
|
Specification |
Details |
|
Engine |
6 cylinders, 6.7 L, FPT N67, Turbo Intercooled, Hi-eSCR2, Structural Engine |
|
Maximum Horsepower |
165 HP (122 kW) @ 1900 RPM, 175 HP (129 kW) with EPM |
|
Maximum Torque |
694 Nm @ 1400 RPM, 737 Nm with EPM |
|
Transmission Type |
Robo-Six, 6 PowerShift Speeds, 5 Robotized Ranges, 30 FWD + 15 REV (Standard), 54 FWD + 27 REV with Creeper (Optional) |
|
Minimum Speed |
3.2 km/h (Standard), 0.4 km/h with Creeper |
|
Maximum Forward Speed |
40 km/h @ 1577 RPM, 50 km/h @ 1971 RPM (Optional) |
Suspension & Brakes
|
Specification |
Details |
|
Front Braking System |
Automatic 4WD Engagement While Braking |
|
Trailer Braking System |
Pneumatic with 2 or 2+1 Lines, with or without 2-Line Hydraulic Brake System (Optional) |
|
Engine Brake |
Standard |
|
Cab Suspension |
Landini Mechanical Suspension System |
Wheels & Tyres
|
Specification |
Details |
|
Front Tyres (Standard) |
600/60R28 (IR 675 mm) |
|
Standard Tyres Rear |
710/60R38 (IR 875 mm) |
Components & Features
|
Specification |
Details |
|
Emissions System |
Stage V, Hi-eSCR2 |
|
Fuel Tank Capacity |
280 L (74 gal) |
|
AdBlue/DEF Tank Capacity |
46 L (12.2 gal) |
|
PTO Type |
Electro-Hydraulic Multidisc Clutch with Modulated Engagement, 540/540E/1000/1000E |
|
Hydraulic System |
Closed-Centre Load Sensing (CCLS), 123 L/min (Standard), 160 L/min (Optional) |
|
Remote Valves |
3 Electro-Hydraulic, 100 L/min (Standard), 4 or 5 Electro-Hydraulic, or 3+2/4+2 Configurations (Optional) |
|
Flow Divider |
3 Sections, 60 L/min per Section with Dedicated Push-Pull Connectors (Optional) |
|
Rear 3-Point Hitch |
Category III, Ball Ends with Quick-Hitch Hooks, Electronically-Controlled with Lower Link Draft, Position, Mixed, Float Control, 9300 kg, 100 mm Ram |
|
Front 3-Point Hitch |
Electronically-Controlled with Position Control, 3500 kg (Optional) |
|
Front PTO |
Electro-Hydraulic Multidisc Clutch with Modulated Engagement, 1000 RPM (Optional) |
|
Wheelbase |
2760 mm (108.7 in) |
|
Shipping Weight |
7000 kg (15432 lb) |
|
Gross Vehicle Weight |
11500 kg (25353 lb) |
|
Operator Platform |
Smart Cab, 4-Post with Landini Mechanical Suspension, 68 dBA Noise Level |
|
Front Axle |
IFS Independent Front Wheel Suspension (Optional) |
|
Rear Axle |
Flanged Type (Standard), Bar Axle Type (Optional) |
