Lamborghini RF. Target 80.4 – 4WD Tractor with SDF Engine
Specifications
|
Specification |
Details |
|
Tractor Model |
Lamborghini RF. Target 80.4 (4WD) |
|
Vehicle Category |
Tractor |
|
Fuel Type |
Diesel |
|
Application |
Agriculture, Landscaping, General Farm Work |
Frame & Drivetrain
|
Specification |
Details |
|
Engine |
SDF, 4 cylinders, 4000 cm³, Turbo Intercooler, Tier 3, Electronic engine management |
|
Gross Horsepower |
80 HP (59 kW) at 2200 rpm |
|
Max Torque |
325 Nm at 1600 rpm |
|
Transmission Type |
Synchronised mechanical, 20+10, Optional 30+15 with supercreeper gear, Synchronised mechanical reverse shuttle |
Suspension & Brakes
|
Specification |
Details |
|
Suspension |
Driving seat with mechanical suspension |
|
Braking System |
Multi-disc wet brakes on all four wheels, Independent parking brake, Hydraulic trailer braking |
Wheels & Tyres
|
Specification |
Details |
|
Tyre Size |
Rear: 360/70R24 |
|
Track Width |
Front: 1166-1442 mm, Rear: 1091-1491 mm |
Components & Features
|
Specification |
Details |
|
PTO Type |
Rear: 540/540ECO/1000 rpm, Ground speed PTO, Mechanical engagement |
|
Hydraulic System |
Open-centre, Pump output: 45 L/min, 4/6 rear auxiliary distributors |
|
Hitch |
Mechanical rear lift control, Lift capacity: 2800 kg |
|
Fuel Tank Capacity |
55 L |
|
Weight |
2650 kg |
|
Maximum Load Capacity |
5000 kg |
|
Dimensions |
Length without rear linkage: 3338 mm, Width: 1588-1988 mm, Height at ROPS: 2380 mm, Wheelbase: 2120 mm, Ground clearance: 270 mm |
|
Features |
Semi-platform, Digital display, Safety frame, Engine speed memory function, Hydrostatic steering with independent pump |
|
Turning Circle |
3700 mm (60°) |
