Lamborghini CF.90 – Crawler Tractor with SDF Engine
Specifications
|
Specification |
Details |
|
Tractor Model |
Lamborghini CF.90 (Tracked) |
|
Vehicle Category |
Crawler Tractor |
|
Fuel Type |
Diesel |
|
Application |
Agriculture, Orchard, Vineyard, Steep Terrain Work |
Frame & Drivetrain
|
Specification |
Details |
|
Engine |
SDF Series 1000, 4 cylinders, 4000 cm³, Turbo Intercooler, Tier III, Electronic engine control, Liquid-oil cooling, Dry air cleaner with safety cartridge and dust ejector, Underhood silencer with lateral exhaust |
|
Gross Horsepower |
85 HP (62.5 kW) at 2200 rpm |
|
Max Torque |
345 Nm at 1600 rpm |
|
Torque Backup |
27.2% |
|
Transmission Type |
Mechanical, 16 FWD + 16 REV with underdrive (min. speed: 1.33 km/h), Optional creeper (min. speed: 0.61 km/h), Dry single disc clutch, Mechanical synchronised shuttle |
Suspension & Brakes
|
Specification |
Details |
|
Suspension |
Platform suspended on Silent-Block mountings, Driver’s seat with mechanical adjustment and safety belt, Optional pneumatic suspension |
|
Braking System |
Oil-immersed band steering brakes with servo-assisted hydrostatic operation, Working brakes (pedal), Clutch-brake operation in sequence with control levers under dashboard |
Wheels & Tracks
|
Specification |
Details |
|
Track Configuration |
Dry chains, 5 bottom rollers, 1 top roller, 37 track shoes, Plate track guards |
|
Track Width |
310 mm, 360 mm, 400 mm |
|
Ground Contact Area |
8990 cm² (310 mm), 10454 cm² (360 mm), 11600 cm² (400 mm) |
|
Track Gauge |
1050 mm (310 mm), 1100 mm (360 mm), 1350 mm (400 mm) |
Components & Features
|
Specification |
Details |
|
PTO Type |
Rear: 540/540ECO rpm, Oil-immersed multiplate clutch, Hydraulic servocontrol |
|
Hydraulic System |
Open-centre, Tandem pump: 50 + 24 L/min, 6/8 auxiliary control valves with flow regulator, Doubled at front |
|
Hitch |
Mechanical rear power lift with draft, depth, and mixed control, Maximum lifting capacity: 3000 kg, Heavy Duty 3-point linkage (fixed or automatic hitching) |
|
Fuel Tank Capacity |
90 L |
|
Weight |
4283 kg (310 mm), 4335 kg (360 mm), 4514 kg (400 mm) |
|
Dimensions |
Length: 3445 mm (310 mm), 3407 mm (360 mm, 400 mm), Width: 1360 mm (310 mm), 1460 mm (360 mm), 1750 mm (400 mm), Height at seat: 1070 mm, Height at dashboard: 1430 mm, Wheelbase: 1650 mm, Ground clearance: 250 mm |
|
Features |
Folding safety frame, Gear levers to right of driver, Shuttle lever to left of driver, 8 front ballast weights (40 kg each), 2+2 side ballast weights (40 kg each) |
