2026 KTM Macina Style FS Prime DI2 – Full-Suspension Carbon Trekking E-Bike
Specifications
|
Specification |
Details |
|
Model |
Macina Style FS Prime DI2 |
|
Application |
Travel, Commute, Long-Distance Trekking |
|
Vehicle Category |
Full-Suspension Carbon Trekking E-Bike |
|
Starting Price (2025) |
€6,299 |
|
Color Options |
Machine Grey Matt (Silver + Black) |
|
Sizes |
XS | S | M | L |
Frame & Drivetrain
|
Specification |
Details |
|
Wheels |
27.5″ |
|
Travel |
100 mm front / 100 mm rear |
|
Frame |
Macina Style Carbon 100 UDH | PT800 Bosch BDU38 |
|
Fork |
SR Suntour XCM34 Air LOR 27.5" 100 mm 15x110 |
|
Shock |
SR Suntour EDGE-EVO 2CR 190×45 mm |
|
Rear Derailleur |
Shimano CUES Di2 U8050-11 SGS shadow |
|
Shifter |
Shimano CUES Di2 EN605 Switch |
|
Crank |
KTM E-TEAM2 ISIS 170 mm |
|
Cassette |
Shimano LG400-11 11-50T |
|
Chain |
Shimano LG500 |
Components & Features
|
Specification |
Details |
|
Motor |
Bosch PERFORMANCE CX BDU3840 – 100 Nm / 750 W peak |
|
Battery |
Bosch PowerTUBE 800 Wh horizontal (PTTL) |
|
Display |
Bosch LED Remote + KIOX 500 TFT Display |
|
Brakes |
Shimano MT402 (3-finger) / MT420 4-piston | RT64 / EM600 180 mm rotors |
|
Wheels |
Ambrosio Sport 25 27.5" |
|
Tires |
Schwalbe Green Marathon Performance GreenGuard 55-584 (front & rear) |
|
Lights |
F: B&M IQ-XM 120–170 Lux HighBeam | R: B&M Toplight 2C |
|
Carrier |
KTM light 42 (Snap-it 2.0 + MonkeyLoad compatible) |
|
Fenders |
SKS A65R PET Trek 27.5" full coverage |
|
Dropper Post |
KTM Line II internal 100 mm travel |
|
Kickstand |
KTM 28" adjustable MY2025 |
|
Weight |
29.9 kg |
|
Permissible Total Weight |
140 kg |
