2026 KTM Macina Gran 610 – Entry-Level Urban Trekking E-Bike
Specifications
|
Specification |
Details |
|
Model |
Macina Gran 610 |
|
Application |
Travel, Commute, Urban Mobility |
|
Vehicle Category |
Entry-Level Urban Trekking E-Bike |
|
Starting Price (2025) |
€3,899 |
|
Color Options |
Burnt Orange Matt |
|
Sizes |
S | M | L | XL |
Frame & Drivetrain
|
Specification |
Details |
|
Wheels |
27.5″ |
|
Travel |
80 mm front |
|
Frame |
Macina Trekking Onroad Alloy6061 | PT750 Bosch Gen.4 |
|
Fork |
SR Suntour XCM 32 ATB coil NLO 29" 80 mm |
|
Rear Derailleur |
Shimano Alivio M3100-9 SGS shadow |
|
Shifter |
Shimano Alivio M3100-9 |
|
Crank |
KTM E-COMP ISIS 170 mm | FSA steel 42T + chainguard |
|
Cassette |
Shimano HG201-9 11-36T |
|
Chain |
Shimano E6070-9 e-bike |
Components & Features
|
Specification |
Details |
|
Motor |
Bosch PERFORMANCE CX Gen.4 SMART SYSTEM – 85 Nm |
|
Battery |
Bosch PowerTUBE 625 Wh SMART SYSTEM horizontal (PTTL) |
|
Display |
Bosch LED Remote + INTUVIA 100 LCD Display |
|
Brakes |
Shimano MT200 2-piston | RT30 CL 180 mm rotors |
|
Wheels |
Ryde Rival30 27.5" on Shimano hubs |
|
Tires |
Schwalbe Al Grounder Performance RT Addix 60-584 |
|
Lights |
F: B&M Lumotec MYC 50 Lux | R: B&M Toplight 2C LED |
|
Carrier |
KTM light (Snap-it 1.0) |
|
Fenders |
SKS A69R 69 mm black matt |
|
Seatpost |
KTM Line Elegance suspension 30.9 mm |
|
Kickstand |
KTM 28" adjustable |
|
Weight |
27.60 kg |
|
Permissible Total Weight |
147 kg |
