2026 KTM Macina Cross CX 810 – Lightweight Gravel-Ready Cross E-Bike
Specifications
|
Specification |
Details |
|
Model |
Macina Cross CX 810 |
|
Application |
Gravel, Light Touring, Fast Commute |
|
Vehicle Category |
Lightweight Gravel/Cross E-Bike |
|
Starting Price (2025) |
€3,999 |
|
Color Options |
Steel Blue Matt (Black + Silver) |
|
Sizes |
S | M | L | XL |
Frame & Drivetrain
|
Specification |
Details |
|
Wheels |
28″ / 700c |
|
Travel |
63 mm front |
|
Frame |
Macina Trekking Onroad Alloy6061 | PT800 Bosch BDU38 |
|
Fork |
SR Suntour NCX32-D Air LO 63 mm |
|
Rear Derailleur |
Shimano CUES U6000-11/10 LG shadow+ |
|
Shifter |
Shimano CUES U6000-11 |
|
Crank |
KTM E-TEAM ISIS 170 mm |
|
Cassette |
Shimano LG400-11 11-50T |
|
Chain |
KMC e11 Sport EPT e-bike |
Components & Features
|
Specification |
Details |
|
Motor |
Bosch PERFORMANCE CX BDU3840 – 100 Nm / 750 W peak |
|
Battery |
Bosch PowerTUBE 800 Wh horizontal (PTTL) |
|
Display |
Bosch LED Remote + KIOX 300 TFT Display |
|
Brakes |
Shimano MT402 / MT420 4-piston | RT64 180 mm / EM600 160 mm |
|
Wheels |
Ambrosio Sport 25 28" |
|
Tires |
Schwalbe Smart Sam Performance Reflex 47-622 |
|
Seatpost |
KTM Line Elegance suspension 30.9 mm |
|
Kickstand |
KTM 28" adjustable |
|
Weight |
24.7 kg |
|
Permissible Total Weight |
143 kg |
