John Deere 5045D GearPro™ 2WD – Agricultural Tractor by John Deere

Images:

1

2

Specifications

Specification	Details
Tractor Model	5045D GearPro™ 2WD
Vehicle Category	Tractor
Fuel Type	Diesel
Application	Agricultural Tractor

Frame & Drivetrain

Specification	Details
Engine Type	John Deere 3029D, 45 HP (33.5 kW), 2100 RPM, 3 Cylinders, Coolant cooled with overflow reservoir, Naturally aspirated
Air Filter	Dry Type, Dual element
Clutch	Single
Transmission Type	Collarshift
Number of Gears	8 Forward + 4 Reverse
Speeds	Forward 2.83 – 30.92 kmph, Reverse 3.71 - 13.43 kmph
3 Point Linkage	Category-II, Automatic depth and draft control (ADDC)
Planetary Gear With Straight Axle	Yes

Suspension & Brakes

Specification	Details
Brakes	Oil immersed disc brakes
Steering Type	Power

Wheels & Tyres

Specification	Details
Front Tyres	6.0 x 16 in (0.15 x 0.41 m), 8 PR
Rear Tyres	13.6 x 28 in (0.34 x 0.71 m), 12 PR

Components & Features

Specification	Details
Maximum Lifting Capacity	1600 kgf
Power Take Off	Independent, 6 Splines, 540 @ 2100 ERPM (Standard), 540 @ 1600 ERPM (Economy, Optional)
Fuel Tank Capacity	60 L
Electrical System	88 Ah, 12 V Battery, 40 Amp. Alternator, 12 V, 2.5 kW Starter motor
Total Weight	1810 kg
Wheelbase	1970 mm
Overall Length	3410 mm
Overall Width	1810 mm
Ground Clearance	415 mm
Turning Radius with Brakes	2900 mm
Service Interval	500 hours
Additional Features	High engine back up torque, Stylish Power Steering, Rubber Mats, Oil Immersed Disc Brakes, Planetary Gear With Straight Axle, Premium seat
Optional Features	Dual Clutch, Dual PTO, Reverse PTO, Roll over protection structure (ROPS) with deluxe seat and seat belt, Adjustable front axle, Mechanical quick raise and lower (MQRL), JDLink (Alerts, Monitoring and Tracking System), Ballast Weights, Canopy, Canopy holder, Draw bar, Tow hook, Wagon hitch, 14.9 x 28 (0.38 x 0.71 m), 12 PR Rear Tyres

* All the images are screenshots!
* Data has been taken from official website (Publicly Available)!
