Indo Farm 4190 DI – Agricultural Tractor by Indo Farm
Specifications
|
Specification |
Details |
|
Tractor Model |
4190 DI |
|
Vehicle Category |
Tractor |
|
Fuel Type |
Diesel |
|
Application |
Agricultural Tractor |
Frame & Drivetrain
|
Specification |
Details |
|
Engine Type |
Four Stroke Direct Injection, Diesel Engine |
|
Engine Power |
90 HP |
|
Number of Cylinders |
Four |
|
Bore/Stroke |
105/118 mm |
|
Rated RPM |
2200 RPM |
|
Air Cleaner |
Dry Type |
|
Fuel Pump |
Inline, Make: Bosch India |
|
Cooling System |
Water cooled |
|
Clutch |
Double, Main Clutch Disc Cerametallic |
|
Transmission Type |
Carraro Synchromesh |
|
Number of Gears |
12 Forward + 12 Reverse |
Suspension & Brakes
|
Specification |
Details |
|
Brakes |
Wet: Oil Immersed Multiple Discs |
|
Brake Actuation |
Mechanical, independent right/left or combined |
|
Parking Brake |
Independent through hand lever; through hand lever, by locking brake pedals |
|
Steering Type |
Hydrostatic Power Steering |
Wheels & Tyres
|
Specification |
Details |
|
Front Tyres |
7.5 x 16 inches (2WD), 11.2 x 24 inches (4WD) |
|
Rear Tyres |
16.9 x 30 inches (2WD), 18.4 x 30 inches (4WD) |
Components & Features
|
Specification |
Details |
|
Maximum Lifting Capacity |
2400 kg |
|
Hydraulic Pump |
Gear Type |
|
Power Take Off |
540 and 1000 RPM, 6 Splines |
|
Total Weight |
2660 kg (2WD), 2960 kg (4WD) |
|
Electrical System |
12 Volts, 88 Ah Battery, Self Starter Motor & Alternator |
|
Minimum Turning Radius |
4.0 m (2WD), 5.0 m (4WD) |
|
Driver’s Seat |
Adjustable |
|
Additional Features |
Oil Immersed Brakes, Aerodynamic Design, Synchromesh Gear Box with 12+12 Speeds Carraro Transmission, Foldable ROPS with Canopy, Heavy 2400 Kgs Lift, Dual PTO Speed, Multipurpose Selective DCV |
|
Wheel Track |
1425–1510 mm (2WD/4WD) |
|
Overall Length |
3900 mm (2WD), 3990 mm (4WD) |
|
Overall Width |
1925 mm (2WD/4WD) |
|
Height (up to steering) |
1790 mm (2WD/4WD) |
|
Ground Clearance |
410 mm (2WD/4WD) |
