Hürlimann Prince Series 35 – 4WD Specialized Tractor for Small Farms and Orchards
Specifications
|
Specification |
Details |
|
Tractor Model |
Hürlimann Prince Series 35 (4WD) |
|
Vehicle Category |
Specialized Tractor |
|
Fuel Type |
Diesel |
|
Application |
Open Field, Small Farms, Hobby Farming, Specialized Crop Farming, Greenhouses, Nurseries, Park Maintenance |
Frame & Drivetrain
|
Specification |
Details |
|
Engine |
Mitsubishi, Direct injection, Liquid-cooled, 4 cylinders, 1500 cc, Euro III |
|
Maximum Horsepower |
39 HP (28.5 kW) |
|
Maximum Torque |
83 Nm |
|
Transmission Type |
Synchronized, 12 forward + 12 reverse speeds, Maximum speed 30 km/h, Electrohydraulic differential locks |
|
Turning Radius |
2600 mm |
Suspension & Brakes
|
Specification |
Details |
|
Suspension |
Platform suspended on Silent-Blocks |
|
Braking System |
Wet disc brakes |
Components & Features
|
Specification |
Details |
|
PTO Type |
Rear PTO: 540/540ECO/1000 rpm, Synchronized PTO, Belly PTO, Optional front PTO 1000 rpm with electrohydraulic clutch |
|
Hydraulic System |
30 l/min pump for rear lift and distributors, 15 l/min pump for steering, Maximum hydraulic pressure 180 bar |
|
Rear Lift |
Maximum lifting capacity 1200 kg |
|
Front Lift |
Maximum lifting capacity 400 kg, Folding coupling bars |
|
Fuel Tank Capacity |
38 L, Optional additional 15 L |
|
Weight with Cab |
1250-1530 kg |
|
Minimum Width |
1220-1358 mm |
