Hürlimann XA Tradition T4i 80 – 4WD Utility Tractor
Specifications
|
Specification |
Details |
|
Tractor Model |
Hürlimann XA Tradition T4i 80 |
|
Vehicle Category |
Utility Tractor |
|
Fuel Type |
Diesel |
|
Application |
Conventional Sowing, Farmyard Tasks, Secondary Tillage |
Frame & Drivetrain
|
Specification |
Details |
|
Engine |
FARMotion, 3 Cylinders, 2,887 cm³, Turbo-Intercooled, Common Rail, EGR, DOC Catalytic Converter, Tier 4i |
|
Maximum Power |
75 HP / 55.4 kW |
|
Homologated Power |
75 HP / 55.4 kW (2000/25/EC) |
|
Maximum Torque |
373 Nm |
|
Transmission Type |
Mechanical, 10+10 or 30+15 FWD/REV with Underdrive and Supercreeper Gears, Max Speed 40 km/h |
|
Frame |
Cab Platform with Silent Blocks |
|
Steering |
Maximum Steering Angle of 55° |
Suspension & Brakes
|
Specification |
Details |
|
Braking System |
Hydraulic Wet Disc Brakes on All Four Wheels |
Components & Features
|
Specification |
Details |
|
PTO Type |
540/1000 RPM, Optional 540/540ECO/1000 RPM, Dry Clutch, Ground Speed PTO, Optional 1000 RPM Front PTO |
|
Hydraulic System |
Open Centre, 42 l/min, 4 or 6 Way Auxiliary Distributors (Convertible to Single/Double Acting) |
|
Rear Lift |
2,650 kg (Flex Bar Mechanical Control) |
|
Driving Position |
Cab Platform with Silent Blocks, Mechanically Sprung Seat (Optional Air Sprung), Suspended Hydraulic Clutch and Brake Pedals, Side-Mounted Shift Levers, Floor-Mounted Differential Lock Pedal |
|
Minimum Width |
1,941 mm |
|
Weight |
3,200 kg (With Cab) |
