2025 Haro Steel Reserve 1 – Mountain Bike

Images:

1

2

3

4

5

Specifications

Specification	Details
Model	Steel Reserve 1
Vehicle Category	Mountain Bike
Application	Dirt jump
Starting Price (2025)	$599.99
Color Options	Matte Black
Sizes	One size

Frame & Drivetrain

Specification	Details
Frame	100% Chromoly frame with integrated headtube, Euro BB, 69° head tube angle, 399mm chainstay
Fork	100% Chromoly One Piece CNC'd 1 1/8" - 1.5" Internally Threaded Steerer Tube, Tapered Legs
Crank	Baseline 8 Spline 165mm
Chain	Baseline Halflink Chain
Bottom Bracket	Double row sealed bearing Euro BB

Components & Features

Specification	Details
Seating	Baseline 2 Piece
Wheels/Tyres	Front - 26x2.4" Kenda Booster, Rear - 26x2.35" Haro MS5, 26", 36 Hole Alloy, Double Wall, Pinned 30mm Inner Width, Alloy double row sealed bearing 3/8" axle front, Alloy sealed Cassette rear
Wheel Size	26"
Brakes	Tektro Mechanical Disc 160mm Rotor
Handlebar	6061 Aluminum 50mm rise, 35mm clamp, 780mm width, 9° back, 5° up
Stem	Aluminum 50mm reach, 35mm clamp
Headset	FSA 45° X 45° ACB Sealed 1-1/8" - 1.5"
Saddle	Baseline 2 Piece
Seatpost	27.2 Alloy Pivotal
Grips	Premium "CK" Grips
Front Hub	Alloy double row sealed bearing 3/8" axle
Rear Hub	Alloy sealed Cassette
Rims	26", 36 Hole Alloy, Double Wall, Pinned 30mm Inner Width
Spokes	36 hole
Pedals	Polycarbonate
Exterior Features	Integrated seat clamp

* All the images are screenshots!
* Data has been taken from official website (Publicly Available)!
