2023 Haro Dana – Freestyle BMX Bike

Images:

1

2

3

4

5

Specifications

Specification	Details
Model	Dana
Vehicle Category	Freestyle BMX Bike
Application	Street riding
Starting Price (2025)	$629.00
Color Options	Bronze, Matte Black
Sizes	20.5" top tube

Frame & Drivetrain

Specification	Details
Frame	Full chromoly, 20.5" top tube, removable brake mounts, integrated head tube, mid bottom bracket
Fork	Full chromoly, threaded steerer tube, tapered legs, 34mm offset
Crank	Haro 3-piece chromoly, 25T, 170mm length
Chain	KMC Z1, 1/8" width
Bottom Bracket	Sealed mid bottom bracket

Components & Features

Specification	Details
Seating	Haro Baseline Pivotal
Wheels/Tyres	Double wall 20" alloy rims, pinned seams, 32mm wide, 36 hole, Haro LaMesa 20 x 2.4
Wheel Size	20"
Handlebar	Haro, chromoly, 9" rise, 12 degree back sweep, 2 degree up sweep
Stem	Haro Baseline forged aluminum top load, 48mm reach
Headset	Integrated, 1-1/8"
Saddle	Haro Baseline Pivotal
Seatpost	Haro Baseline Pivotal alloy, 200mm
Grips	Haro Baseline flangeless, 163mm
Front Hub	Alloy front hub, sealed bearings, 3/8" axle
Rear Hub	Sealed cassette rear hub, 9T driver, 14mm axle
Rims	Double wall 20" alloy rims, pinned seams, 32mm wide, 36 hole
Pedals	Haro Baseline poly platform, chromoly axles
Exterior Features	Nylon sleeves with alloy core pegs

* All the images are screenshots!
* Data has been taken from official website (Publicly Available)!
