2025 GT Grade Carbon Elite – Gravel Bike
Specifications
|
Specification |
Details |
|
Model |
Grade Carbon Elite |
|
Vehicle Category |
Gravel Bike |
|
Application |
Gravel riding |
|
Starting Price (2025) |
$2,999.99 |
|
Color Options |
Wet Cement |
|
Sizes |
S, M, L, XL |
Frame & Drivetrain
|
Specification |
Details |
|
Frame |
Grade Carbon Frame, Triple Triangle Design feat. Floating Seatstays, 12x142mm Thru Axle, 45mm Max Tire Width, Dual Fiber Dynamics, Internal cable routing |
|
Fork |
Grade Carbon Fork, 1.5 Tapered Carbon Steerer, 12x100 Thru Axle |
|
Crank |
Shimano GRX RX6001, 46/30T |
|
Chain |
KMC X10, 10-speed |
|
Bottom Bracket |
Shimano RS500 BSA |
|
Shifters |
Shimano GRX 400 2x10 |
|
Front Derailleur |
Shimano GRX RX-400 |
|
Rear Derailleur |
Shimano GRX RX400, Shadow Plus |
Components & Features
|
Specification |
Details |
|
Seating |
WTB Silverado |
|
Wheels/Tyres |
WTB Vulpine TCS Light 700x40c, Dual DNA Compound, TCS Aramid Bead, WTB ST i23 TCS 2.0 28h rims, Tubeless Ready, Formula CL-712 12x100mm Centerlock front hub, Formula 12x142mm Centerlock rear hub |
|
Wheel Size |
700c |
|
Brakes |
Shimano GRX 400, 160/160mm RT30 Rotors |
|
Handlebar |
GT DropTune RS, Alloy, 16° Flare (S/M - 42cm, L - 44cm, XL - 46cm) |
|
Stem |
GT 3D Forged SL Alloy, 31.8 |
|
Headset |
FSA No.42 ACB |
|
Saddle |
WTB Silverado |
|
Seatpost |
GT Alloy, 27.2mm (S/M/L - 350mm, XL - 400mm) |
|
Grips |
GT Gravel Grip Premium Tape |
|
Front Hub |
Formula CL-712, 12x100mm Centerlock |
|
Rear Hub |
Formula, 12x142mm Centerlock |
|
Rims |
WTB ST i23 TCS 2.0, 28h, Tubeless Ready |
|
Spokes |
28 hole |
|
Exterior Features |
Downtube and chainstay protection, Internal cable routing |
