2025 GMC Canyon Elevation – 310 HP Mid-Size Pickup Truck
Specifications
|
Specification |
Details |
|
Model |
Canyon Elevation |
|
Vehicle Category |
Mid-Size Pickup Truck |
|
Fuel Type |
Gasoline |
|
Application |
Work, commuting, light off-road driving |
|
Starting Price(2025) |
$38,400 (2WD, Crew Cab), $41,700 (4WD, Crew Cab), including $2,400 destination charge; as shown: $38,895 |
|
Color Options |
Exterior: Deep Bronze Metallic ($495), Desert Sun ($495), Moonstone Gray Metallic ($495), Onyx Black ($495), Rapids Metallic ($495), Sterling Metallic ($495), Summit White (no cost), Volcanic Red Tintcoat ($645); Interior: Jet Black (cloth), Jet Black with Jet Black accents (cloth) |
Frame & Drivetrain
|
Specification |
Details |
|
Engine |
2.7L TurboMax Inline 4-cylinder, gasoline, direct injection, DOHC, variable valve timing |
|
Gross Horsepower |
310 HP @ 5600 RPM |
|
Torque |
430 lb-ft @ 3000 RPM |
|
Transmission Type |
8-speed automatic |
Suspension & Brakes
|
Specification |
Details |
|
Suspension |
Front: Independent coil-over-shock, Rear: Solid axle with semi-elliptic two-stage multi-leaf springs, lifted off-road tuned with 2 in. factory lift |
|
Brakes |
4-wheel disc brakes, 13.4 in. front rotors, 13.3 in. rear rotors, 4-wheel ABS |
Wheels & Tyres
|
Specification |
Details |
|
Wheels & Tyres |
18 x 8.5 in. dark gray painted aluminum wheels, 265/65R18 all-terrain blackwall tires |
Components & Features
|
Specification |
Details |
|
Chassis |
Body-on-frame, GM midsize truck platform |
|
Seating |
5 passengers (Crew Cab), cloth bucket seats, 6-way manual driver seat, 4-way manual passenger seat, split-folding rear seatback |
|
Infotainment |
11.3 in. diagonal touchscreen with Google built-in, wireless Apple CarPlay/Android Auto, 6-speaker audio, SiriusXM 3-month trial, 11 in. digital Driver Information Center |
|
Safety Features |
Canyon Pro Safety: Forward Collision Alert, Automatic Emergency Braking, Front Pedestrian/Bicyclist Braking, Lane Keep Assist with Lane Departure Warning, Following Distance Indicator, IntelliBeam; standard: High Definition Rear Vision Camera, Hitch View, Blind Zone Steering Assist with Trailering; optional: rear parking sensors, surround-view camera, adaptive cruise control |
|
Convenience Features |
LED headlamps, heated power mirrors, keyless entry with push-button start, single-zone automatic climate control, ProGrade Trailering System, trailer brake controller, optional: MultiStow tailgate, power sunroof, remote start, 120V bed/console outlets, sliding rear window, EZ-Lift tailgate |
|
Cargo Capacity |
41.9 cu.ft. (short bed, Crew Cab), max payload: 1670 lbs, max towing: 7700 lbs |
|
Fuel Tank |
21.4 gal |
|
Weight |
4410 lbs (2WD Crew Cab), 4650 lbs (4WD Crew Cab) |
|
Width |
72.4 in. (1839 mm, without mirrors); 84.4 in. (2144 mm, with mirrors) |
|
Length |
213.2 in. (5415 mm, Crew Cab short bed) |
|
Max Height |
79.8 in. (2027 mm) |
|
Ground Clearance |
9.6 in. (244 mm) |
