Specification

Details

Model

Revolt 2

Vehicle Category

Gravel Bike

Application

Gravel riding

Starting Price (2025)

$1,450 USD

Color Options

Ocean Storm, Icicle White

Sizes

XS (5'1" - 5'5"), S (5'3" - 5'7"), M (5'7" - 5'11"), M/L (5'9" - 6'1"), L (5'10" - 6'3"), XL (6'2" - 6'7")

Specification

Details

Frame

ALUXX-grade aluminum, 12x142mm thru-axle, disc, flip chip dropout

Fork

Advanced-grade composite, full-composite OverDrive steerer, 12mm thru-axle, disc

Crank

Shimano FC-U6030-2, 32/46 (XS: 170mm, S: 170mm, M: 172.5mm, M/L: 172.5mm, L: 175mm, XL: 175mm)

Chain

KMC X11

Bottom Bracket

Shimano, threaded

Shifters

Shimano CUES U3030, 2x9 or Shimano Sora, 2x9

Front Derailleur

Shimano CUES U6030 or Shimano Sora

Rear Derailleur

Shimano CUES U4020 or Shimano Sora, long cage

Specification

Details

Seating

Giant Grit

Cargo Capacity

Six water bottle mounts (two on down tube, two on fork, one on top tube, one on seat tube), rack and fender compatible

Wheels/Tyres

Giant CrossCut AT 2, 700x38c, tubeless

Wheel Size

700c

Brakes

Shimano BR-RS305 mechanical, Giant MPH rotors [F]160mm, [R]160mm

Brake Levers

Shimano CUES U3030 hydraulic or Shimano Sora

Handlebar

Giant Contact XR Ergo-Control, 31.8mm (XS: 42cm, S: 42cm, M: 44cm, M/L: 44cm, L: 46cm, XL: 46cm)

Stem

Giant Contact, 8-degree (XS: 50mm, S: 60mm, M: 70mm, M/L: 80mm, L: 80mm, XL: 90mm)

Headset

Giant integrated

Saddle

Giant Grit

Seatpost

Giant D-Fuse, alloy, 14mm offset

Grips

Cork tape with gel

Front Hub

Giant alloy, 12mm thru-axle

Rear Hub

Giant alloy, 12mm thru-axle

Rims

Giant S-X2, alloy

Spokes

Stainless

Exterior Features

Tubeless prepared, 53mm max tire size in "long" flip chip position, 45mm max tire size in "short" flip chip position, flip chip dropout, 30.9mm round or dropper seatpost compatible
