2025 Fuji Ambient EVO 27 1.3 – E-Mountain Bike
Specifications
|
Specification |
Details |
|
Model |
Ambient EVO 27 1.3 |
|
Vehicle Category |
E-Mountain Bike |
|
Application |
Trail riding |
|
Starting Price (2025) |
$3,799.99 |
|
Color Options |
Opal green |
|
Sizes |
M (17"), L (19"), XL (21") |
Frame & Drivetrain
|
Specification |
Details |
|
Frame |
Fuji A6-SL alloy front and rear triangle with down tube for integrated Bosch Power Tube 625-500Wh battery, Bosch Gen.4 motor cover, tapered 1 1/8" - 1.5" head tube, post disc mount, Boost 148 x 12mm cold-forged dropout and replaceable hanger |
|
Fork |
SR Suntour XCR34-Air 29, Lockout, tapered alloy steerer, Boost 110 x 15mm thru axle, travel 120mm, 34mm stanchions |
|
Crank |
FSA CK-745/IS, Bosch Gen.4, 32T, with chainguard, for Boost |
|
Chain |
Shimano CN-HG601-11, 11-speed |
|
Bottom Bracket |
Bosch System ISIS drive |
|
Shifters |
Shimano Deore |
|
Rear Derailleur |
Shimano Deore, 11-speed (11-51T) |
Components & Features
|
Specification |
Details |
|
Seating |
WTB High Tail Trail, Comp, e-Bike specific saddle, steel rail |
|
Fuel Type |
Electric (Bosch Performance CX, 250W, 85Nm, 25km/h max assist) |
|
Wheels/Tyres |
Shimano MT400-Boost CL 15mm thru axle disc, 32H front, Shimano MT400-Boost CL 12mm thru axle disc, 32H rear, WTB ST i29 TCS 2.0 double wall 29" rims, Continental Trail King, 60-622, ShieldWall, foldable, TL |
|
Wheel Size |
29" |
|
Brakes |
TRP Slate-T4 and X2, 4-piston front, 2-piston rear hydraulic disc, 203mm rotors |
|
Brake Levers |
TRP Slate-T4, 2 finger lever |
|
Handlebar |
Oval Concepts 205 flat bar, 6061 alloy, +/- 5mm rise, 9 degree sweep, 31.8mm clamp, width: 760mm |
|
Stem |
3D-forged 6061 alloy, 7 degree, 31.8mm clamp, length: 17" - 35mm, 19" - 45mm, 21" - 60mm |
|
Headset |
FSA NO.57B, 1 1/8" - 1.5", retainer bearings |
|
Saddle |
WTB High Tail Trail, Comp, e-Bike specific saddle, steel rail |
|
Seatpost |
Oval Concepts 300, 6061 alloy micro adjust, 30.9mm diameter |
|
Grips |
WTB Waffel, single LO, dual density Kraton |
|
Front Hub |
Shimano MT400-Boost CL 15mm thru axle disc, 32H |
|
Rear Hub |
Shimano MT400-Boost CL 12mm thru axle disc, 32H |
|
Rims |
WTB ST i29 TCS 2.0 double wall 29" |
|
Spokes |
14/15g stainless steel |
|
Pedals |
Alloy platform, chromoly axle |
|
Exterior Features |
Bosch Purion display |
