2024 Ford Ranger Raptor – Off-Road Midsize Pickup Truck
Specifications
|
Specification |
Details |
|
Model |
Ranger Raptor |
|
Vehicle Category |
Midsize Pickup Truck |
|
Fuel Type |
Gasoline |
|
Application |
Midsize truck, towing, off-road |
|
Starting Price (2025) |
$55,720, excludes destination/delivery fee, taxes, and optional equipment |
|
Color Options |
Exterior: Oxford White, Iconic Silver, Carbonized Gray, Shadow Black, Cactus Gray, Hot Pepper Red, Velocity Blue, Azure Gray Metallic Tri-Coat, Shelter Green; Interior: Ebony leather |
Frame & Drivetrain
|
Specification |
Details |
|
Engine |
3.0L EcoBoost V6 (405 HP, 430 lb-ft) |
|
Gross Horsepower |
405 HP @ 5,500 rpm |
|
Torque |
430 lb-ft @ 3,000 rpm |
|
Transmission Type |
10-speed automatic |
|
Drivetrain |
Four-Wheel Drive (4WD) with advanced 4x4 system |
|
Max Towing Capacity |
5,510 lbs |
Suspension & Brakes
|
Specification |
Details |
|
Front Suspension |
Independent double-wishbone with FOX live valve shocks |
|
Rear Suspension |
Solid axle with FOX live valve shocks and Watts linkage |
|
Brakes |
Four-wheel disc brakes with ABS, 12.9-in front vented disc, 12.1-in rear vented disc |
Components & Features
|
Specification |
Details |
|
Seating |
5 passengers |
|
Interior Features |
12-inch LCD touchscreen with SYNC 4A, Apple CarPlay, Android Auto, 10-speaker B&O Sound System, USB ports (2 "A", 1 "C"), dual-zone electronic automatic temperature control, leather-trimmed seats, heated front seats, 8-way power driver seat with power lumbar, 6-way power passenger seat, Ford Co-Pilot360 (pre-collision assist with automatic emergency braking, lane-keeping system, blind-spot monitoring, rear cross-traffic alert, rearview camera, auto high beams), Ford Co-Pilot360 Assist+ (adaptive cruise control with stop-and-go, lane centering, evasive steering assist), FordPass Connect, push-button start, 12.4-inch digital instrument cluster, heated steering wheel, wireless charging pad, Terrain Management System with 7 modes (Normal, Eco, Sport, Tow/Haul, Slippery, Mud/Ruts, Baja), front and rear locking differentials |
|
Exterior Features |
17-inch aluminum wheels, 285/70R17 all-terrain tires, LED headlamps, LED fog lamps, LED taillamps, power sideview mirrors with memory, 6-foot bed with cargo tie-downs, bed lighting, power sliding rear window, skid plates, Raptor badging, tow hooks, widened track |
|
Fuel Economy and Performance |
EPA-estimated 16/18 MPG (city/highway, 4WD), 405 HP, 430 lb-ft, 0–60 mph in ~5.0 seconds, top speed ~130 MPH, payload 1,411 lbs, cargo volume 43.3 cu-ft (bed), GVWR 6,550 lbs |
|
Fuel Tank |
20.3 gal |
|
Weight |
5,325 lbs |
|
Width |
85.8 in. (excluding mirrors) |
|
Length |
210.6 in. |
|
Max Height |
74.4 in. |
|
Ground Clearance |
10.7 in. |
