Ferrari Vega 85 AI-Tractor DUALSTEER® – 4WD Specialized Tractor for Orchards and Vineyards
Specifications
|
Specification |
Details |
|
Tractor Model |
Ferrari Vega 85 AI-Tractor DUALSTEER® (4WD) |
|
Vehicle Category |
Specialized Tractor |
|
Fuel Type |
Diesel |
|
Application |
Orchards, Vineyards, Greenhouses, Nurseries, Municipality Activities |
Frame & Drivetrain
|
Specification |
Details |
|
Engine |
Kohler KDI 2504 TCR, 4 In-Line Cylinders, 16 Valves, 2482 cc, Turbo/Intercooler, Common Rail Direct Injection, Stage V |
|
Maximum Horsepower |
75.3 HP (55.4 kW) @ 2300 RPM |
|
Maximum Torque |
300 Nm @ 1500 RPM |
|
Transmission Type |
32-Speed (16 FWD + 16 REV) with Easy Plus™ Clutch and "Artificial Intelligence" for Clutch, Brakes, and Electro-Hydraulic Reverser Management |
|
Clutch |
Multidisc in Oil Bath with Electronically-Managed and Proportional Hydraulic Control, Power Clutch System, Smart Brake & Go Function |
Suspension & Brakes
|
Specification |
Details |
|
Frame |
Isodiametric with Articulated Chassis and Steering Wheels, DUALSTEER® System |
|
Braking System |
Multidisc in Oil Bath with Hydrostatic Control, Acting on Four Wheels with Hill Start Assist, Independent Manoeuvring Brakes Acting on Rear Wheels |
|
Differential Lock |
Front and Rear, Simultaneous or Rear Only with Electro-Hydraulic Control |
Components & Features
|
Specification |
Details |
|
PTO Type |
Independent from Gearbox, Synchronised with Forwarding Speed, Negative Safety Hydraulic Brake, Multidisc in Oil Bath Clutch with Electro-Hydraulic Control, 540/540E RPM (Optional: 540/1000) |
|
Hydraulic System |
Dual Circuit with Independent Pumps and Heat Exchanger |
|
Rear Lift |
Ball Joint Lifting Capacity 2300 kg |
|
Front Lift |
Optional, Two-Cylinder, Complete with Front Bumper and 4 Front Hydraulic Outlets, Lifting Capacity 800 kg |
|
Joystick |
Optional, Proportional Electronic Control of Lifts and Control Valves, Potentiometer for Hydraulic Flow Adjustment, Remote PTO Engagement and Throttle Control, Storage Armrest, Additional Buttons for AI-Tractor Driving Modes |
|
Steering |
DUALSTEER® System with Hydrostatic Steering Acting on Front Wheels and Central Joint |
|
Cab Options |
Optional VISTA PRO: Pressurised, Category 4 Approved, Four-Post Frame with Conical Profile, LED Lights, Heating and Air-Conditioning System |
