Fendt IDEAL 7 – 483 HP Combine Harvester for Efficient Harvesting
Specifications
|
Specification |
Details |
|
Model |
Fendt IDEAL 7 |
|
Vehicle Category |
Combine Harvester |
|
Fuel Type |
Diesel |
|
Application |
Grain, soybeans, corn |
Frame & Drivetrain
|
Specification |
Details |
|
Engine |
AGCO Power, 7 cylinders, 9.8 L, Stage V |
|
Gross Horsepower |
483 HP (355 kW) at 1800 rpm |
|
Transmission Type |
MotionShift gearbox, 2-speed, electrical gear shift, max speed 40 km/h, optional AllDrive 4WD |
Suspension & Brakes
|
Specification |
Details |
|
Suspension |
Optional front axle suspension |
Components & Features
|
Specification |
Details |
|
Threshing System |
Single rotor, 600 mm diameter, 4838 mm length, 280-1160 rpm, 0.83 m² threshing area, 1.44 m² separation area, 2.27 m² total separation area |
|
Cleaning System |
Cyclone cleaning system, IDEALbalance grain pans, 2.71 m² top sieve, 2.19 m² lower sieve, 4.9 m² total sieve area, fan speed 150-1350 rpm, double ventilated steps, returns indicator |
|
Grain Tank |
12500 L, optional Streamer 210 (17100 L, 210 l/s), standard Streamer 140 (12500 L, 140 l/s), max unloading height 4.28 m, StreamerGates discharge rate adjustment |
|
Straw Chopper |
BaseCut (56 serrated knives) or ShortCut (112 serrated knives), optional chopper change from cab, standard chaff spreader, optional ActiveSpread radial spreader or SwingFlow |
|
Header |
PowerFlow 7.7-10.7 m, 1220 cuts/min, TerraControl II guidance, automatic reel speed, optional electric rape knife, hydraulic reel drive, EHU, optional AutoDock, optional variable table drive, optional HP hydraulic cutting angle adjustment, 4 intake chains, hydraulic reverse, optional dust ejector |
|
Fuel Tank Capacity |
1000/1250 L (diesel), 180 L (AdBlue) |
|
Width |
3290-3890 mm (without table) |
|
Length |
9127 mm (without table) |
|
Height |
3990 mm |
|
Features |
Vision cab, air-suspended driver seat, optional deluxe seat, automatic climate control, electrically adjustable heated mirrors, additional wide-angle mirror, optional full LED work lights, optional radio with MP3 and Bluetooth, rear-view camera, optional multi-camera system, cooler compartment, loss indicator, optional ProSound system, PowerFold swingable entry ladder, optional additional tablet holder, Fendt Variotronic with 10.4" Varioterminal, Fendt Dashboard, optional VarioDoc Pro, standard Fendt Connect, optional TI Headland, yield and moisture measurement, optional yield mapping, optional air compressor, optional variable table drive |
