Fendt 1151 Vario MT – Agricultural Tractor by Fendt
Specifications
|
Specification |
Details |
|
Tractor Model |
1151 Vario MT |
|
Vehicle Category |
Tracked Tractor |
|
Fuel Type |
Diesel |
|
Application |
Agricultural Tractor |
Frame & Drivetrain
|
Specification |
Details |
|
Engine Type |
MAN 6 Cylinder, Turbocharged, Intercooled with AGR, DOC, DPF, SCR |
|
Engine Power |
376 kW / 511 HP (ECE R 120) |
|
Number of Cylinders |
Six |
|
Engine Capacity |
15200 CC |
|
Engine Rated RPM |
1730 |
|
Max Torque |
2500 Nm @ 1450 RPM |
|
Transmission Type |
TA 400T (VarioDrive) |
|
Speed Range |
Forward: 0–40 km/h |
Suspension & Brakes
|
Specification |
Details |
|
Suspension |
SmartRide, 8° Swing Angle |
Wheels & Tyres
|
Specification |
Details |
|
Track Type |
27.5 inches Standard AG; 27.5 inches Extreme AG (Option) |
Components & Features
|
Specification |
Details |
|
Drive |
Tracked |
|
Maximum Lifting Capacity |
9072 daN (Rear) |
|
Hydraulics Type |
Variable Flow Pump |
|
Hydraulic Pump |
220 l/min (Standard); 440 l/min (Option) |
|
Power Take Off |
1000/1000E RPM |
|
Total Weight |
18805 kg (Unladen); 27000 kg (Max) |
|
Fuel Tank Capacity |
1320 Litres (Diesel); 135 Litres (AdBlue) |
|
Track Width |
2286 mm (Standard Track) |
|
Overall Width |
2979 mm (Standard Track) |
|
Wheel Base |
3000 mm |
|
Overall Length |
6758 mm |
|
Height |
3546 mm (Comfort Cab) |
|
Ground Clearance |
359 mm |
